SANYO DENKI P50B05020DXS00主軸電機
1.產 品 資 料 介 紹：
- 中小功率精準驅動：作為 P5 系列經典主軸型號，P50B05020DXS00 額定功率適配 200W 級應用場景，采用優化電磁設計實現高效能量轉換，在小型數控機床、精密加工設備中可提供穩定動力輸出，兼顧能效與驅動精度。
- 高分辨率定位控制：搭載高精度光學編碼器（參考系列 2000 線及以上配置），配合全閉環反饋系統，能實現微米級位置定位，在 PCB 銑削、小型模具加工等場景中，有效提升工件加工表面質量與尺寸一致性。
- 寬速域平穩運行：轉速調節范圍覆蓋低速恒轉矩到高速輕載區間，最高轉速可達 3000rpm 以上，通過優化轉子結構降低齒槽轉矩，低速運行時轉速波動量顯著降低，適配精密研磨、精細雕刻等多速度需求場景。
- 全系列驅動器兼容：可無縫匹配同品牌 PZ、PU、PV 等系列伺服驅動器，無需額外調整參數即可實現聯動控制，在老舊日系小型設備升級維護中，能直接替換原有 P5 系列電機，大幅降低適配調試成本。
- 強化耐環境設計：采用高剛性軸承與優化動平衡工藝，運行噪音低于 60dB，振動幅度控制在 0.1mm 以內；機身具備 IP54 及以上防護等級，可抵御加工車間粉塵與輕微油污，適配 0~40℃常規工業環境。
- 低耗易維護結構：通過低損耗電磁材料應用，電機能量損失較傳統型號降低 10% 以上；采用一體化飛線設計，簡化接線流程，配合標準化部件選型，后期更換維護便捷，降低設備停機時間。
- 多層級安全防護：內置過載、過流、過熱三重保護模塊，當負載超過額定值 150% 時自動切斷輸出，同時具備欠壓、過壓保護功能，防止電機及關聯設備因異常工況損壞，提升生產安全性。
- 小型設備專項適配：憑借緊湊機身設計（參考系列 54×54mm 法蘭尺寸）與精準控制性能，廣泛應用于小型數控機床、精密檢測儀器、紡織機械主軸等領域，既是新設備配套優選，也是小型老舊設備維護的標桿替換件。
SANYO DENKI P50B05020DXS00主軸電機 英文資料：
Small and Medium Power Precision Drive: As a classic spindle model of the P5 series, P50B05020DXS00 has a rated power suitable for 200W level application scenarios. It adopts optimized electromagnetic design to achieve efficient energy conversion and can provide stable power output in small CNC machine tools and precision machining equipment, balancing energy efficiency and drive accuracy.
High resolution positioning control: Equipped with a high-precision optical encoder (reference series 2000 line and above configuration), combined with a fully closed-loop feedback system, it can achieve micrometer level position positioning, effectively improving the surface quality and size consistency of workpiece processing in PCB milling, small mold processing and other scenarios.
Smooth operation in a wide speed range: The speed adjustment range covers the low-speed constant torque to high-speed light load range, with a maximum speed of over 3000rpm. By optimizing the rotor structure to reduce cogging torque, the speed fluctuation during low-speed operation is significantly reduced, making it suitable for multi speed demand scenarios such as precision grinding and fine carving.
Full range drive compatibility: It can seamlessly match servo drives of the same brand such as PZ, PU, PV, etc., without the need for additional parameter adjustment to achieve linkage control. In the upgrade and maintenance of old Japanese small equipment, it can directly ｒｅｐｌａｃｅ the original P5 series motor, greatly reducing the cost of adaptation and debugging.
Enhanced environmental resistance design: using high rigidity bearings and optimized dynamic balancing technology, the operating noise is below 60dB, and the vibration amplitude is controlled within 0.1mm; The body has a protection level of IP54 or above, which can resist dust and slight oil stains in the processing workshop, and is suitable for conventional industrial environments ranging from 0 to 40 ℃.
Low consumption and easy maintenance structure: By using low loss electromagnetic materials, the energy loss of the motor is reduced by more than 10% compared to traditional models; Adopting an integrated flying wire design, simplifying the wiring process, and coordinating with standardized component selection, it is easy to ｒｅｐｌａｃｅ and maintain in the later stage, reducing equipment downtime.
Multi level safety protection: Equipped with triple protection modules for overload, overcurrent, and overheating, it automatically cuts off the output when the load exceeds 150% of the rated value. At the same time, it has undervoltage and overvoltage protection functions to prevent motor and related equipment from being damaged due to abnormal working conditions and improve production safety.
Specialized adaptation for small equipment: With a compact body design (reference series 54 × 54mm flange size) and precise control performance, it is widely used in small CNC machine tools, precision testing instruments, textile machinery spindles and other fields. It is not only the preferred choice for new equipment matching, but also the benchmark replacement for maintenance of small and old equipment.
SANYO DENKI P50B05020DXS00主軸電機 產品展示
產品視頻
