AEG PC-E984-685R 可編程控制器模塊
1.產 品 資 料 介 紹：
中文資料：
AEG PC-E984-685R 可編程控制器模塊 是施耐德電氣（Schneider Electric）旗下 AEG 品牌早期推出的一款工業級 PLC 控制模塊，主要用于工業自動化控制系統中的邏輯處理、設備控制與通信集成。它屬于 Modicon 984 系列，這一系列曾廣泛應用于過程控制、工廠自動化、電力系統和重型機械控制中。
一、產品基本信息
型號：PC-E984-685R
制造商：AEG / Modicon（現為施耐德電氣旗下品牌）
產品類別：可編程邏輯控制器（PLC）主模塊
系列歸屬：Modicon 984 系列（高端模塊）
二、功能特性
高性能 CPU 處理能力
搭載高速工業處理器，適合多任務邏輯處理，支持復雜控制邏輯和數據運算。
適用于中到大型自動化控制項目。
模塊化架構
支持 I/O 模塊熱插拔（視配置而定），具備良好的可擴展性與兼容性。
可連接多種 984 系列 I/O 擴展模塊。
支持多種通信協議
可通過附加通信模塊接入 Modbus、Modbus Plus、TCP/IP、SY/MAX 等工業通信網絡。
適合與上位機、SCADA、人機界面（HMI）等系統進行實時數據交互。
強大的編程支持
使用 Modsoft、Concept、ProWORX 等編程軟件進行邏輯開發。
支持多種編程語言，包括梯形圖（Ladder）、功能塊圖（FBD）等。
工業級耐用性設計
工作溫度范圍廣，抗電磁干擾能力強，適應各種工業現場環境。
采用冗余電源設計，可支持熱備份配置（取決于系統整體架構）。
三、技術參數概覽（典型配置）
| 項目 | 參數說明 |
|---|---|
| CPU | 工業級高性能處理器（型號依版本） |
| 存儲容量 | RAM 和非易失性存儲器（配置可選） |
| 通信端口 | 串口 RS-232/485、Modbus Plus 等 |
| 編程接口 | 通用串口或 Modbus 通信 |
| 電源輸入 | 5V/24V DC（需外接電源模塊） |
| 安裝方式 | 模塊化導軌式或背板式安裝 |
| 使用環境溫度 | 0 ～ 60°C（依具體安裝情況） |
| 抗干擾能力 | 工業級電磁兼容標準 |
| 尺寸/重量 | 模塊化結構，安裝尺寸標準化 |
英文資料：
The AEG PC-E984-685R programmable controller module is an industrial grade PLC control module launched early by the AEG brand under Schneider Electric. It is mainly used for logic processing, equipment control, and communication integration in industrial automation control systems. It belongs to the Modicon 984 series, which has been widely used in process control, factory automation, power systems, and heavy machinery control.
1、 Basic Product Information
Model: PC-E984-685R
Manufacturer: AEG/Modicon (now a brand under Schneider Electric)
Product Category: Programmable Logic Controller (PLC) Main Module
Series affiliation: Modicon 984 series (high-end module)
2、 Functional characteristics
High performance CPU processing capability
Equipped with high-speed industrial processors, suitable for multitasking logic processing, supporting complex control logic and data operations.
Suitable for medium to large-scale automation control projects.
Modular architecture
Supports hot plugging of I/O modules (depending on configuration), with good scalability and compatibility.
Can connect multiple 984 series I/O expansion modules.
Support multiple communication protocols
It can be connected to industrial communication networks such as Modbus, Modbus Plus, TCP/IP, SY/MAX through additional communication modules.
Suitable for use with upper computers SCADA、 Real time data exchange is carried out through human-machine interface (HMI) and other systems.
Powerful programming support
Use programming software such as Modsoft, Concept, ProWORX for logic development.
Supports multiple programming languages, including ladder diagram (Ladder), functional block diagram (FBD), etc.
Industrial grade durability design
Wide working temperature range, strong electromagnetic interference resistance, and adaptability to various industrial site environments.
Adopting redundant power supply design, it can support hot backup configuration (depending on the overall system architecture).
3、 Overview of Technical Parameters (Typical Configuration)
Project parameter description
CPU industrial grade high-performance processor (model by version)
Storage capacity: RAM and non-volatile memory (optional configuration)
Communication port serial port RS-232/485, Modbus Plus, etc
Programming interface: Universal serial port or Modbus communication
Power input 5V/24V DC (requires external power module)
Installation method: Modular rail or backplate installation
The operating environment temperature ranges from 0 to 60 ° C (depending on the specific installation situation)
Industrial level electromagnetic compatibility standard for anti-interference capability
Modular structure for size/weight, standardized installation dimensions
