ABB DILA-22繼電器
1.產 品 資 料 介 紹:
中文資料:
DILA-22 是 Eaton(伊頓) 生產的一款 輔助繼電器/接觸器,用于控制輔助電路中的信號切換和遠程控制。它通常與主接觸器或繼電器配合使用,廣泛應用于工業自動化、電力系統和機械控制領域。
主要特點
輔助觸點配置:2常開(NO)+ 2常閉(NC),適用于多種控制需求。
高可靠性:觸點采用耐磨材料,確保長期穩定運行。
模塊化設計:可與 DIL 系列主接觸器兼容,易于擴展。
緊湊結構:支持 DIN 導軌安裝,節省空間。
高機械耐久性:額定壽命高,適用于頻繁操作的場合。
技術規格
額定電壓:24V、110V、230V AC/DC(視具體型號而定)。
額定電流:10A(適用于低功率控制電路)。
觸點配置:2NO + 2NC。
安裝方式:DIN導軌 或 螺釘固定。
工作溫度范圍:-25°C 至 +55°C,適應惡劣環境。
應用領域
工業自動化:用于PLC、繼電器控制系統的輔助信號切換。
電力控制系統:用于變電站、配電柜中的狀態指示和信號傳輸。
機械設備:控制電機、報警裝置、照明系統等。
DILA-22 繼電器結構緊湊、性能穩定,是工業和商業電控系統中常見的輔助控制組件。
英文資料:
DILA-22 is an auxiliary relay/contactor produced by Eaton, used for controlling signal switching and remote control in auxiliary circuits. It is usually used in conjunction with main contactors or relays and is widely used in industrial automation, power systems, and mechanical control fields.
main features
Auxiliary contact configuration: 2 normally open (NO)+2 normally closed (NC), suitable for various control requirements.
High reliability: The contacts are made of wear-resistant materials to ensure long-term stable operation.
Modular design: compatible with DIL series main contactors and easy to expand.
Compact structure: Supports DIN rail installation, saving space.
High mechanical durability: With a high rated lifespan, it is suitable for frequent operations.
technical specifications
Rated voltage: 24V, 110V, 230V AC/DC (depending on the specific model).
Rated current: 10A (suitable for low-power control circuits).
Contact configuration: 2NO+2NC.
Installation method: DIN rail or screw fixation.
Working temperature range:- 25 ° C to+55 ° C, suitable for harsh environments.
application area
Industrial automation: Used for auxiliary signal switching in PLC and relay control systems.
Power control system: used for status indication and signal transmission in substations and distribution cabinets.
Mechanical equipment: control motors, alarm devices, lighting systems, etc.
DILA-22 relay has a compact structure and stable performance, and is a common auxiliary control component in industrial and commercial electronic control systems.
2.產 品 展 示
