ABB AI810模擬輸入模塊
1.產 品 資 料 介 紹：
中文資料：
AI810 是 ABB 生產的 模擬輸入模塊，屬于 S800 I/O 系列，用于過程自動化和工業控制系統中的模擬信號采集。該模塊能夠處理 電流（mA）或電壓（V） 信號，廣泛應用于傳感器、變送器等設備的數據采集。
主要特點
8個模擬輸入通道，支持多種信號類型。
支持電流/電壓輸入，適用于各種工業傳感器。
高精度A/D轉換，確保數據采集的準確性。
故障檢測功能，包括斷線檢測，提高系統可靠性。
兼容ABB S800 I/O系統，易于集成到AC 800M等DCS控制系統。
技術規格
輸入類型：
電壓模式：±10V
電流模式：0/4-20mA
通道數：8個獨立輸入通道
分辨率：12位 A/D 轉換
掃描時間：2ms/通道，支持快速數據更新
安裝方式：DIN導軌或機架安裝
隔離保護：通道與系統之間電氣隔離，提高抗干擾能力
英文資料：
AI810 is an analog input module produced by ABB, belonging to the S800 I/O series, used for analog signal acquisition in process automation and industrial control systems. This module is capable of processing current (mA) or voltage (V) signals and is widely used for data acquisition in devices such as sensors and transmitters.
main features
8 analog input channels, supporting multiple signal types.
Supports current/voltage input and is suitable for various industrial sensors.
High precision A/D conversion ensures the accuracy of data acquisition.
Fault detection function, including wire breakage detection, improves system reliability.
Compatible with ABB S800 I/O system, easy to integrate into DCS control systems such as AC 800M.
technical specifications
Input type:
Voltage mode: ± 10V
Current mode: 0/4-20mA
Number of channels: 8 independent input channels
Resolution: 12 bit A/D conversion
Scanning time: 2ms/channel, supports fast data updates
Installation method: DIN rail or rack installation
Isolation protection: Electrical isolation between channels and systems to improve anti-interference ability
2.產 品 展 示
