ABB  QUNT-PS/1AC/24DC/20電源供應模塊

1.產 品 資 料 介 紹：

中文資料：

QUINT-PS/1AC/24DC/20 是菲尼克斯電氣（Phoenix Contact）推出的一款高性能DIN導軌電源模塊，專為工業自動化和控制系統提供穩定的直流電源。

主要特點

• 輸入電壓范圍：支持單相交流輸入，電壓范圍為100 V AC至240 V AC，適用于全球不同電網標準。

• 輸出性能：

  • 額定輸出電壓：24 V DC

  • 額定輸出電流：20 A，提供480 W的功率，適用于高負載設備

  • 動態功率提升：可在短時間內提供高達30 A的電流（持續5秒），適應電機或大型負載的啟動需求

• SFB技術（選擇性熔斷）：在短路情況下可瞬間提供120 A電流（持續12毫秒），確?？焖儆|發標準斷路器，精準定位故障，提高系統安全性

• 高效率：在230 V AC輸入時，效率可達94%，減少能耗和熱量，提高系統穩定性

• 安裝方式：采用DIN導軌安裝，支持螺釘連接，便于控制柜集成

應用領域

• 工業自動化：為PLC、HMI等控制設備提供穩定的24 V DC電源

• 過程控制：適用于石油、化工、制藥等行業的傳感器和執行器供電

• 電力系統：用于變電站、配電系統中的繼電保護裝置和通信設備供電

• 交通運輸：在鐵路信號系統、機場照明、交通控制設備等應用場景中提供可靠電源

QUINT-PS/1AC/24DC/20 以其高可靠性和強大保護功能，廣泛應用于需要高可用性和穩定性的工業環境。

英文資料：

QUINT-PS/1AC/24DC/20 is a high-performance DIN rail power module launched by Phoenix Contact, designed to provide stable DC power for industrial automation and control systems.

main features

Input voltage range: Supports single-phase AC input, with a voltage range of 100 V AC to 240 V AC, suitable for different global power grid standards.

Output performance:

Rated output voltage: 24 V DC

Rated output current: 20 A, providing 480 W of power, suitable for high load equipment

Dynamic power boost: can provide up to 30 A of current in a short period of time (lasting for 5 seconds), suitable for the starting needs of motors or large loads

SFB technology (selective fuse): can instantly provide 120 A current (lasting 12 milliseconds) in the event of a short circuit, ensuring fast triggering of standard circuit breakers, precise fault location, and improving system safety

High efficiency: At 230 V AC input, the efficiency can reach 94%, reducing energy consumption and heat, and improving system stability

Installation method: DIN rail installation is adopted, supporting screw connection for easy integration of control cabinet

application area

Industrial automation: providing stable 24V DC power supply for control equipment such as PLC and HMI

Process Control: Suitable for powering sensors and actuators in industries such as petroleum, chemical, and pharmaceutical

Power system: used for supplying power to relay protection devices and communication equipment in substations and distribution systems

Transportation: Providing reliable power supply in application scenarios such as railway signal systems, airport lighting, and traffic control equipment

QUINT-PS/1AC/24DC/20 is widely used in industrial environments that require high availability and stability due to its high reliability and powerful protection functions.

2.產      品      展      示
