GE IS200AEADH4A輸入終端板
1.產 品 資 料 介 紹：
中文資料：
GE IS200AEADH4A 輸入終端板 是通用電氣（GE）Mark VI 或 Mark VIe 控制系統中的一款關鍵 I/O 模塊配套的輸入終端板（Input Terminal Board），廣泛應用于燃?xì)廨啓C(jī)、蒸汽輪機及其他工業自動化控制系統中，用于模擬信號的接入和調理。
一、基本信息
| 項目 | 內容 |
|---|---|
| 產品型號 | IS200AEADH4A |
| 名稱 | AEAD 輸入終端板（Analog/Exciter/Attenuator/Distribution） |
| 制造商 | GE (General Electric) |
| 系統平臺 | Mark VI / Mark VIe 控制系統 |
| 功能類型 | 模擬輸入信號終端接線板（Terminal Board for Analog Inputs） |
二、核心功能
模擬輸入信號接入
提供通道接線端子，用于接收外部傳感器、變送器等設備的模擬輸入信號（如電壓、電流等）。
信號調理與分配
包含隔離、濾波、電壓分壓、短路保護等功能，以確保信號穩定可靠地傳輸至控制模塊。
與 I/O 模塊配合使用
通常與 IS200AEAAH1A 或類似模擬采集模塊配合使用，通過連接線纜（例如 JT1、JT2 接頭）實現信號傳輸。
高可靠性設計
工業級設計，適用于苛刻環境；具備抗干擾能力和過壓保護。
三、技術參數（典型值）
| 參數 | 說明 |
|---|---|
| 模擬輸入信號類型 | 0–5V、±5V、0–20mA、4–20mA（取決于系統配置） |
| 通道數量 | 一般支持 10–16 路模擬輸入 |
| 端子類型 | 插拔式接線端子，帶編號 |
| 電氣隔離 | 輸入/控制信號之間隔離 |
| 連接方式 | 與主板通過電纜連接（通常為信號線束或排線） |
| 安裝方式 | DIN 導軌或面板固定螺絲安裝 |
| 適用環境溫度 | -30°C 至 +65°C（依 GE 工業標準） |
英文資料：
The GE IS200AEADH4A input terminal board is a key I/O module matching input terminal board in the General Electric (GE) Mark VI or Mark VIe control system. It is widely used in gas turbines, steam turbines, and other industrial automation control systems for analog signal access and conditioning.
1、 Basic Information
Project Content
Product model IS200AEADH4A
Name: AEAD Input Terminal Board (Analog/Encoder/Attenuator/Distribution)
Manufacturer GE (General Electric)
System Platform Mark VI/Mark VIe Control System
Function type: Terminal Board for Analog Input
2、 Core functions
Analog input signal access
Provide channel wiring terminals for receiving analog input signals (such as voltage, current, etc.) from external sensors, transmitters, and other devices.
Signal conditioning and distribution
It includes functions such as isolation, filtering, voltage division, and short-circuit protection to ensure stable and reliable transmission of signals to the control module.
Used in conjunction with I/O modules
Usually used in conjunction with IS200AEAAH1A or similar analog acquisition modules, signal transmission is achieved through connecting cables (such as JT1, JT2 connectors).
High reliability design
Industrial grade design, suitable for harsh environments; Capable of anti-interference and overvoltage protection.
3、 Technical parameters (typical values)
Parameter Description
Analog input signal types: 0-5V, ± 5V, 0-20mA, 4-20mA (depending on system configuration)
The number of channels generally supports 10-16 analog inputs
Terminal type: Plug in terminal block with serial number
Isolation between electrical isolation input/control signals
The connection method is to connect the motherboard through a cable (usually a signal harness or ribbon cable)
Installation method: DIN rail or panel fixed screw installation
Applicable ambient temperature -30 ° C to+65 ° C (according to GE industrial standards)
