ABB XVC770BE101 3BHE021083R0101接口板

1.產 品 資 料 介 紹：

中文資料：

XVC770BE101 3BHE021083R0101 是ABB公司生產的一款工業級接口板（Interface Board），通常用于高壓變頻器、電機控制系統或自動化設備中，負責信號轉換、通信或擴展功能。以下是詳細分析：

1. 產品基本信息

• 型號：XVC770BE101（功能型號）

• 訂貨號：3BHE021083R0101（ABB唯一標識）

• 品牌：ABB（全球電力和自動化技術巨頭）

• 類型：接口板（可能屬于ABB ACS800、ACS880 或其他變頻器系列）

• 用途：信號處理、I/O擴展、通信協議轉換

2. 主要功能

該接口板通常用于以下場景：
? 信號轉換（模擬量?數字量、RS485?光纖等）
? I/O擴展（增加DI/DO、AI/AO接口）
? 通信協議支持（如Modbus、Profibus、CANopen等）
? 系統監控（狀態反饋、故障診斷）
? 變頻器控制（與ABB ACS系列變頻器配套使用）

3. 典型應用領域

(1) 工業變頻器系統（如ABB ACS800/ACS880）

• 用于高壓/低壓變頻器的信號接口擴展

• 連接PLC、DCS或HMI（人機界面）

• 實現遠程監控和參數調整

(2) 自動化產線與電機控制

• 伺服電機、大型工業電機的控制接口

• 與ABB 800xA 或 AC500 PLC 系統集成

(3) 能源與電力系統

• 風電變流器、光伏逆變器的通信接口

• 智能電網設備的數據采集與傳輸

(4) 軌道交通與船舶

• 牽引系統（如地鐵、高鐵）的變頻控制

• 船舶電力推進系統的信號管理

英文資料：

XVC770BE101 3BHE02103R0101 is an industrial grade interface board produced by ABB, commonly used in high-voltage frequency converters, motor control systems, or automation equipment, responsible for signal conversion, communication, or expansion functions. The following is a detailed analysis:

1. Basic product information

Model: XVC770BE101 (functional model)

Order number: 3BHE02103R0101 (ABB unique identifier)

Brand: ABB (global power and automation technology giant)

Type: Interface board (may belong to ABB ACS800, ACS880 or other frequency converter series)

Purpose: Signal processing, I/O expansion, communication protocol conversion

2. Main functions

This interface board is typically used in the following scenarios:

?  Signal conversion (analog quantity) ? Numerical quantity RS485 ? Fiber optics, etc

?  I/O expansion (adding DI/DO, AI/AO interfaces)

?  Communication protocol support (such as Modbus, Profibus, CANopen, etc.)

?  System monitoring (status feedback, fault diagnosis)

?  Variable frequency drive control (used in conjunction with ABB ACS series variable frequency drives)

3. Typical application areas

(1) Industrial frequency converter system (such as ABB ACS800/ACS880)

Signal interface expansion for high/low voltage frequency converters

Connect PLC, DCS or HMI (human-machine interface)

Realize remote monitoring and parameter adjustment

(2) Automated production line and motor control

Control interfaces for servo motors and large industrial motors

Integrate with ABB 800xA or AC500 PLC systems

(3) Energy and Power Systems

Communication interfaces for wind power inverters and photovoltaic inverters

Data Collection and Transmission of Smart Grid Equipment

(4) Rail Transit and Ships

Variable frequency control of traction systems (such as subways and high-speed trains)

Signal Management of Ship Electric Propulsion System
