ABB UFC789AE 38HE014022P102激勵控制板

1.產 品 資 料 介 紹：

中文資料：

UFC789AE 38HE014022P102 是ABB公司生產的一款激勵控制板（Excitation Control Board），主要用于同步電機、發電機或大型變頻驅動系統的磁場（勵磁）控制。以下是詳細技術分析：

1. 產品基本信息

• 型號：UFC789AE

• 訂貨號：38HE014022P102（ABB唯一標識）

• 品牌：ABB（電力和工業自動化領域領導者）

• 類型：勵磁控制板

• 典型應用：

  • 同步電機/發電機的磁場電流調節

  • 高壓變頻器（如ACS5000）的勵磁單元

  • 工業驅動系統（如壓縮機、泵）的功率因數控制

2. 核心功能

? 磁場電流精確控制（PID調節，±0.5%精度）
? 無功功率（VAR）補償（用于電網穩定性）
? 自動電壓調節（AVR）
? 保護功能：過勵磁/欠勵磁、失步保護、磁場短路檢測
? 通信接口：支持Modbus、Profibus或ABB專用協議

3. 典型應用場景

(1) 電力發電與輸配

• 同步發電機的勵磁控制系統（火電/水電/核電）

• 電網黑啟動過程中的電壓建立

(2) 工業驅動系統

• 大型同步電機驅動（如壓縮機、軋鋼機）

• 高壓變頻器（如ACS5000）的勵磁電源管理

(3) 新能源領域

• 風力發電雙饋電機的轉子勵磁控制

• 光伏逆變器站的動態無功補償

英文資料：

UFC789AE 38HE014022P102 is an Excitation Control Board produced by ABB, mainly used for magnetic field (excitation) control of synchronous motors, generators, or large variable frequency drive systems. The following is a detailed technical analysis:

1. Basic product information

model: UFC789AE

Order number: 38HE014022P102 (ABB unique identifier)

Brand: ABB (leader in power and industrial automation)

Type: Excitation Control Board

Typical applications:

Magnetic field current regulation of synchronous motors/generators

Excitation unit of high-voltage frequency converter (such as ACS5000)

Power factor control of industrial drive systems (such as compressors, pumps)

2. Core functions

?  Precise control of magnetic field current (PID regulation, ± 0.5% accuracy)

?  Reactive power (VAR) compensation (for grid stability)

?  Automatic Voltage Regulation (AVR)

?  Protection functions: overexcitation/underexcitation, out of step protection, magnetic field short circuit detection

?  Communication interface: Supports Modbus, Profibus, or ABB specific protocols

3. Typical application scenarios

(1) Electricity generation and transmission distribution

Excitation control system for synchronous generators (thermal power/hydropower/nuclear power)

Voltage establishment during black start process of power grid

(2) Industrial Drive System

Large synchronous motor drive (such as compressors, rolling mills)

Excitation power management of high-voltage frequency converters (such as ACS5000)

(3) In the field of new energy

Rotor excitation control of doubly fed wind turbine generator

Dynamic reactive power compensation of photovoltaic inverter station

2.產      品      展      示
