ABB LWN2660-6E 3BHL000986P7002電源模塊

1.產 品 資 料 介 紹：

中文資料：

LWN2660-6E 3BHL000986P7002 是ABB公司生產的一款工業級電源模塊，屬于高壓/大功率電力電子設備的關鍵組件，主要用于為變頻器、驅動系統或自動化設備提供穩定可靠的直流或交流電源轉換。

1. 產品基本信息

• 型號：LWN2660-6E

• 訂貨號：3BHL000986P7002（ABB唯一標識）

• 品牌：ABB（電力和自動化領域全球領導品牌）

• 類型：電源模塊（可能屬于 ACS880、PCS100 或 Symphony Plus 系列）

• 用途：

  • 為變頻器提供直流母線電壓（如ACS880的DC-link供電）

  • 工業驅動系統的輔助電源

  • 可再生能源系統的功率轉換

2. 核心功能

? 高壓AC/DC或DC/DC轉換（如三相交流→直流母線）
? 穩壓輸出（為IGBT驅動器、控制電路供電）
? 短路/過載保護（工業級安全設計）
? 低諧波干擾（符合EN 61000-3-12等EMC標準）
? 模塊化設計（支持冗余或并聯運行）

3. 典型應用場景

(1) 工業變頻器系統（如ABB ACS880）

• 為變頻器直流母線（DC-link）提供穩定電壓

• 支持多模塊并聯，擴展功率容量

(2) 新能源發電（風電/光伏）

• 風電變流器的輔助電源

• 光伏逆變器的DC/DC升壓模塊

(3) 電力電子與儲能

• HVDC（高壓直流輸電）系統的輔助供電

• 電池儲能系統（BESS）的電源管理

(4) 軌道交通與船舶

• 牽引變流器的輔助電源模塊

• 船舶電力系統的直流供電

英文資料：

LWN2660-6E 3BHL000986P7002 is an industrial grade power module produced by ABB, which is a key component of high-voltage/high-power power electronic equipment. It is mainly used to provide stable and reliable DC or AC power conversion for frequency converters, drive systems, or automation equipment.

1. Basic product information

model: LWN2660-6E

Order number: 3BHL000986P7002 (ABB unique identifier)

Brand: ABB (Global Leader in Power and Automation)

Type: Power module (may belong to ACS880, PCS100 or Symphony Plus series)

Purpose:

Provide DC bus voltage for the frequency converter (such as DC link power supply for ACS880)

Auxiliary power supply for industrial drive systems

Power Conversion of Renewable Energy Systems

2. Core functions

?  High voltage AC/DC or DC/DC conversion (such as three-phase AC → DC bus)

?  Stabilized output (supplying power to IGBT drivers and control circuits)

?  Short circuit/overload protection (industrial grade safety design)

?  Low harmonic interference (compliant with EMC standards such as EN 61000-3-12)

?  Modular design (supporting redundant or parallel operation)

3. Typical application scenarios

(1) Industrial frequency converter system (such as ABB ACS880)

Provide stable voltage for the DC link of the frequency converter

Support parallel connection of multiple modules to expand power capacity

(2) New energy generation (wind power/photovoltaic)

Auxiliary power supply for wind power converter

DC/DC boost module of photovoltaic inverter

(3) Power Electronics and Energy Storage

Auxiliary power supply for HVDC (High Voltage Direct Current Transmission) system

Power Management of Battery Energy Storage System (BESS)

(4) Rail Transit and Ships

Auxiliary power module of traction converter

DC power supply for ship power system

2.產      品      展      示
