Control Techniques  SK2403變頻器

1.產 品 資 料 介 紹：

產品概述

Control Techniques SK2403 變頻器 屬于 Unidrive SK 系列，是一款高性能交流變頻調速裝置。該系列以緊湊設計、靈活擴展和高可靠性著稱，適用于需要精確速度與轉矩控制的工業場景。SK2403 提供多種控制模式，包括開環矢量控制與 V/F 控制，滿足從簡單風機到復雜生產線的不同需求。

技術參數

• 輸入電壓范圍：三相 380–480V AC

• 功率等級：約 11kW（15HP）

• 控制模式：V/F 控制、開環矢量控制

• 頻率范圍：0–550 Hz 可調

• 過載能力：150% 60 秒 / 180% 短時

• 接口配置：內置數字與模擬 I/O，支持?jǐn)U展模塊（通信、反饋等）

• 保護功能：過壓、欠壓、過流、過載、過熱、接地故障等

應用場景

• 輸送與搬運系統：實現平穩啟停與速度調節，減少機械沖擊。

• 風機與泵類設備：通過變頻調速節能降耗，提升運行效率。

• 紡織與造紙行業：提供精準速度控制，保證生產線穩定性。

• 金屬加工與木工機械：支持高動態響應，滿足復雜工藝的驅動需求。

• 食品與包裝機械：提高靈活性和生產效率，適應多工序自動化控制。

產品優勢

1. 結構緊湊：安裝空間需求小，方便嵌入機柜或設備內。

2. 性能穩定：高可靠性設計，適應長時間連續運行。

3. 靈活擴展：支持多種選配模塊，如 Profibus、Ethernet、DeviceNet 等通信接口。

4. 節能高效：智能能耗管理，降低運行成本。

5. 易于操作：內置操作鍵盤與參數設置向?qū)В喕{(diào)試過程。

Control Techniques   SK2403變頻器 英文資料：

Product Overview

The Control Techniques SK2403 frequency converter belongs to the Unidrive SK series and is a high-performance AC variable frequency speed regulation device. This series is known for its compact design, flexible expansion, and high reliability, making it suitable for industrial scenarios that require precise speed and torque control. SK2403 offers multiple control modes, including open-loop vector control and V/F control, to meet different needs from simple fans to complex production lines.

Technical Specifications

Input voltage range: three-phase 380-480V AC

Power level: approximately 11kW (15HP)

Control modes: V/F control, open-loop vector control

Frequency range: 0-550 Hz adjustable

Overload capacity: 150% 60 seconds/180% short-term

Interface configuration: Built in digital and analog I/O, supporting expansion modules (communication, feedback, etc.)

Protection functions: overvoltage, undervoltage, overcurrent, overload, overheating, grounding faults, etc

Application scenarios

Conveyor and handling system: achieve smooth start stop and speed adjustment, reduce mechanical impact.

Fan and pump equipment: Energy saving and consumption reducing through variable frequency speed regulation, improving operational efficiency.

Textile and paper industry: providing precise speed control to ensure production line stability.

Metal processing and woodworking machinery: supports high dynamic response to meet the driving requirements of complex processes.

Food and packaging machinery: Improve flexibility and production efficiency, adapt to multi process automation control.

Product advantages

Compact structure: requires minimal installation space, making it easy to embed into cabinets or equipment.

Stable performance: Designed with high reliability, suitable for long-term continuous operation.

Flexible Expansion: Supports multiple optional modules, such as Profibus, Ethernet, DeviceNet, and other communication interfaces.

Energy saving and efficient: intelligent energy management to reduce operating costs.

Easy to operate: Built in operation keyboard and parameter setting wizard, simplifying the debugging process.

Control Techniques  SK2403變頻器 產品展示

 產品視頻
