Control Techniques  MP350A4R直流調速器

1.產 品 資 料 介 紹：

產品概述

Control Techniques MP350A4R 直流調速器 屬于 Mentor MP 系列，是一款高性能直流電機驅動器。該系列專為需要精確速度、轉矩和位置控制的應用而設計，廣泛應用于冶金、紙機、塑料擠出、起重機等連續重載行業。MP350A4R 提供先進的電流環與速度環控制算法，支持現代化通信接口和靈活擴展，具備極高的可靠性和適應性。

技術參數

• 額定電流：350A

• 輸入電源：三相交流 400V（典型）

• 電機類型：勵磁直流電機

• 控制模式：速度控制、轉矩控制、電流控制

• 反饋方式：支持測速發電機、編碼器及無傳感器運行

• 過載能力：150% 60 秒 / 200% 短時峰值

• 冷卻方式：強制風冷

• 保護功能：過流、過壓、欠壓、過溫、接地故障、缺相保護

應用場景

• 冶金行業：軋鋼機、卷揚機等高扭矩工況

• 造紙機械：紙機主傳動，確保張力控制與同步運行

• 塑料與橡膠設備：擠出機、壓延機，保持恒定速度與工藝穩定性

• 起重與提升：起重機、絞車系統，提供高動態響應

• 能源與礦業：輸送機、磨機驅動，保證重載下的穩定運行

產品優勢

1. 高性能控制：先進的電流與速度環算法，確保動態響應和控制精度。

2. 可靠耐用：工業級設計，適合惡劣環境和長時間重載運行。

3. 強大擴展性：支持 Profibus、DeviceNet、Ethernet 等總線通訊模塊。

4. 節能優化：提升直流電機系統的效率，延長電機與設備壽命。

5. 便捷操作：配套參數化工具和人機界面，簡化調試與維護。

Control Techniques  MP350A4R直流調速器 英文資料：

Product Overview

The Control Techniques MP350A4R DC speed regulator belongs to the Mentor MP series and is a high-performance DC motor driver. This series is designed for applications that require precise speed, torque, and position control, and is widely used in continuous heavy-duty industries such as metallurgy, paper machines, plastic extrusion, and cranes. MP350A4R provides advanced current loop and speed loop control algorithms, supports modern communication interfaces and flexible expansion, and has extremely high reliability and adaptability.

Technical Specifications

Rated current: 350A

Input power supply: three-phase AC 400V (typical)

Motor type: Excited DC motor

Control modes: speed control, torque control, current control

Feedback method: Supports speed generator, encoder, and sensorless operation

Overload capacity: 150% 60 seconds/200% short-term peak value

Cooling method: forced air cooling

Protection functions: overcurrent, overvoltage, undervoltage, overtemperature, ground fault, phase loss protection

Application scenarios

Metallurgical industry: high torque working conditions such as rolling mills and winches

Paper making machinery: The main transmission of the paper machine ensures tension control and synchronous operation

Plastic and rubber equipment: extruders, calenders, maintaining constant speed and process stability

Lifting and hoisting: Crane, winch system, providing high dynamic response

Energy and Mining: Conveyor and Mill Drive to Ensure Stable Operation under Heavy Load

Product advantages

High performance control: Advanced current and speed loop algorithms ensure dynamic response and control accuracy.

Reliable and durable: Industrial grade design, suitable for harsh environments and long-term heavy-duty operation.

Powerful scalability: Supports bus communication modules such as Profibus, DeviceNet, Ethernet, etc.

Energy saving optimization: Improve the efficiency of DC motor systems and extend the lifespan of motors and equipment.

Convenient operation: equipped with parameterized tools and human-machine interface, simplifying debugging and maintenance.

Control Techniques MP350A4R直流調速器 產品展示

 產品視頻
