ABB HIES308461R0012水冷電阻器

1.產 品 資 料 介 紹：

中文資料：

HIES308461R0012 是ABB公司生產的一款工業級水冷電阻器，主要用于高功率電力電子系統中的能量耗散和動態制動。以下是詳細技術分析：

1. 產品基本信息

• 型號：HIES308461R0012

• 類型：強制水冷式制動電阻/負載電阻

• 品牌：ABB（電力和自動化領域領導者）

• 典型應用：

  • 變頻器/逆變器的動態制動單元

  • 大功率測試負載

  • 新能源發電系統（風電/光伏）的過壓保護

2. 核心特點

? 水冷散熱設計：

• 冷卻效率比風冷高5-10倍

• 允許更高功率密度（典型值：200-500kW/m3）

• 水溫要求：通常5-35°C（需防凍）

? 高能承受能力：

• 短時過載能力可達300%額定功率（10秒）

• 低電感設計（<1μH）適合高頻開關場合

? 模塊化結構：

• 多電阻單元并聯擴展功率

• 法蘭式水管連接（DN15-DN25標準接口）

3. 典型應用場景

(1) 工業驅動系統

• 用于ACS880/ACS800變頻器的制動單元

• 軋鋼機/起重機的快速制動能量吸收

(2) 新能源領域

• 風力發電機的緊急制動負載

• 光伏逆變器的過壓保護電阻

(3) 測試與實驗

• 大功率電機/變壓器的測試負載

• 船舶推進系統的模擬負載

英文資料：

HIES308461R0012 is an industrial grade water-cooled resistor produced by ABB, mainly used for energy dissipation and dynamic braking in high-power power electronic systems. The following is a detailed technical analysis:

1. Basic product information

model: HIES308461R0012

Type: Forced water-cooled braking resistor/load resistor

Brand: ABB (leader in power and automation)

Typical applications:

Dynamic braking unit of frequency converter/inverter

High power test load

Overvoltage protection for new energy generation systems (wind/photovoltaic)

2. Core Features

?  Water cooling and heat dissipation design:

Cooling efficiency 5-10 times higher than air cooling

Allow for higher power density (typical value: 200-500kW/m 3)

Water temperature requirement: usually 5-35 ° C (antifreeze required)

?  High energy endurance:

Short term overload capacity can reach 300% of rated power (10 seconds)

Low inductance design (<1 μ H) suitable for high-frequency switching applications

?  Modular structure:

Parallel extension power of multiple resistor units

Flange type water pipe connection (DN15-DN25 standard interface)

3. Typical application scenarios

(1) Industrial Drive System

Braking unit for ACS880/ACS800 frequency converter

Rapid braking energy absorption of steel rolling mill/crane

(2) In the field of new energy

Emergency braking load of wind turbines

Overvoltage protection resistor for photovoltaic inverters

(3) Testing and experimentation

Test load for high-power motors/transformers

Simulation load of ship propulsion system
