Hirschmann MM3-2FXM2 2TX1媒體模塊
1.產 品 資 料 介 紹：
中文資料：
Hirschmann MM3-2FXM2 2TX1 是 Hirschmann 提供的一款高性能工業媒體模塊，專為網絡中設備之間的數據傳輸提供擴展支持。該模塊設計用于提供兩路光纖接口（2FX）與一路以太網接口（2TX1），實現光纖到以太網的信號轉換，廣泛應用于工業自動化和通信網絡中，特別是在需要長距離傳輸和網絡冗余的環境中。
主要技術參數
| 項目 | 參數說明 |
|---|---|
| 模塊類型 | 光纖/以太網媒體轉換模塊 |
| 光纖接口類型 | 2 路 SC/LC 光纖接口（單?；蚨嗄＃?/td> |
| 以太網接口類型 | 1 路 10/100/1000 Mbps 以太網端口 |
| 光纖接口標準 | 支持 IEEE 802.3 10BASE-FL、100BASE-FX、1000BASE-SX |
| 網絡冗余支持 | 支持網絡冗余（如 RSTP、PRP、Hirschmann 提供的工業協議） |
| 電源供應 | 24V DC（典型） |
| 工作溫度范圍 | -40°C 至 +75°C |
| 環境適應性 | 防塵、防水，符合 IP30 或更高等級 |
| 安裝方式 | DIN 導軌安裝（標準安裝方式） |
| 使用標準 | IEC 61850-3、IEEE 802.3、UL/CE 認證 |
| LED 狀態指示 | 提供操作和故障指示燈 |
光纖與以太網信號轉換：支持從光纖到以太網的數據流轉換，適用于工業網絡的長距離傳輸需求
冗余與可靠性：支持高可用性和冗余網絡配置，減少系統故障時間，確保網絡的高穩定性
高溫工作環境：適用于嚴苛的工業環境，支持極端溫度下穩定工作
緊湊設計：小巧的模塊設計，適用于空間有限的控制柜或設備中
擴展性：可與 Hirschmann 其他工業網絡設備無縫集成，滿足多種網絡拓?fù)湫枨?/p>
易于安裝與維護：簡單的 DIN 導軌安裝，提供便捷的系統監控和管理功能
強大的協議支持：兼容多種工業協議和網絡標準，支持多種網絡架構
英文資料：
Hirschmann MM3-2FXM2 2TX1 is a high-performance industrial media module provided by Hirschmann, designed to provide extended support for data transmission between devices in networks. This module is designed to provide two fiber optic interfaces (2FX) and one Ethernet interface (2TX1) to achieve signal conversion from fiber optic to Ethernet. It is widely used in industrial automation and communication networks, especially in environments that require long-distance transmission and network redundancy.
Main technical parameters
Project parameter description
Module type: Fiber optic/Ethernet media conversion module
Fiber interface type: 2-channel SC/LC fiber interface (single-mode or multi-mode)
Ethernet interface type: 1-channel 10/100/1000 Mbps Ethernet port
The fiber optic interface standard supports IEEE 802.3 10BASE-FL, 100BASE-FX, and 1000BASE-SX
Network redundancy support supports network redundancy (such as RSTP, PRP, industrial protocols provided by Hirschmann)
Power supply 24V DC (typical)
Working temperature range -40 ° C to+75 ° C
Environmental adaptability: dustproof and waterproof, compliant with IP30 or higher levels
Installation method: DIN rail installation (standard installation method)
Use standard IEC 61850-3, IEEE 802.3, UL/CE certification
LED status indicator provides operation and fault indicator lights
Product Features
Fiber optic and Ethernet signal conversion: supports data stream conversion from fiber optic to Ethernet, suitable for long-distance transmission needs in industrial networks
Redundancy and Reliability: Supports high availability and redundant network configurations, reduces system failure time, and ensures high network stability
High temperature working environment: suitable for harsh industrial environments, supporting stable operation under extreme temperatures
Compact design: A compact module design suitable for control cabinets or devices with limited space
Scalability: Seamless integration with other Hirschmann industrial network devices to meet various network topology requirements
Easy to install and maintain: Simple DIN rail installation, providing convenient system monitoring and management functions
Powerful protocol support: compatible with multiple industrial protocols and network standards, supporting multiple network architectures
2.產 品 展 示
