DELTA TAU  ACC51E 4096模擬編碼器

1.產 品 資 料 介 紹：

中文資料：

Delta Tau ACC-51E — 高精度模擬編碼器輸入模塊，專用于 UMAC 控制系統，支持解析度高達 4096 倍的正余弦模擬編碼器 輸入。

二、產品用途

該模塊用于接收來自模擬正余弦編碼器（如1Vpp標準）信號，并將其轉換為 UMAC 系統可識別的數字位置信號，實現高分辨率位置控制與反饋。

三、主要特點

• 輸入類型：支持雙通道 1Vpp 正弦 / 余弦模擬編碼器信號

• 分辨率：最高可達 4096 倍插值（即每圈最大可實現百萬級分辨率）

• 支持通道數：典型配置支持 2 通道編碼器輸入（可擴展）

• 編碼器接口：兼容 Heidenhain、Renishaw 等主流模擬編碼器

• 通信方式：與 UMAC 背板直接連接，系統識別為子模塊

• 輔助輸入輸出：部分版本含參考信號輸入（如 Z 相）或數字 I/O

四、技術參數

五、應用領域

該模塊適合用于需要高分辨率位置檢測與閉環控制的高端設備，例如：

• 半導體制造設備

• 精密機床

• 高速機器人定位系統

• 醫療影像機械（如 CT、MRI 定位）

• 自動光學檢測系統（AOI）

• 精密測量平臺

英文資料：

Delta Tau ACC-51E - High precision analog encoder input module, specifically designed for UMAC control systems, supporting sine and cosine analog encoder inputs with resolutions up to 4096 times.

2、 Product Usage

This module is used to receive signals from analog sine and cosine encoders (such as 1Vpp standard) and convert them into digital position signals recognizable by UMAC systems, achieving high-resolution position control and feedback.

3、 Main features

Input type: Supports dual channel 1Vpp sine/cosine analog encoder signal

Resolution: Up to 4096 times interpolation (i.e. maximum resolution of millions per cycle)

Number of supported channels: Typical configuration supports 2-channel encoder input (expandable)

Encoder interface: compatible with mainstream analog encoders such as Heidenhain and Renishaw

Communication method: directly connected to UMAC backplane, recognized by the system as a submodule

Auxiliary input/output: Some versions include reference signal input (such as Z-phase) or digital I/O

4、 Technical parameters

Parameter Name Technical Indicator Description

Analog signal type 1Vpp sine and cosine (differential)

Maximum resolution 4096 times interpolation

Encoder input channels 2 standard channels (some versions can be extended)

The signal frequency range typically supports signal frequencies up to 200kHz

High linearity of accuracy and stability, suitable for precision motion control applications

Installation form 3U plug-in card, inserted into UMAC host backplane

The power supply method is provided by the host with ± 15V DC power

5、 Application Fields

This module is suitable for high-end devices that require high-resolution position detection and closed-loop control, such as:

Semiconductor Manufacturing Equipment

Precision machine tool

High speed robot positioning system

Medical imaging machinery (such as CT, MRI positioning)

Automatic Optical Inspection System (AOI)

Precision measurement platform

2.產      品      展      示
