Bailey  NTMP01終端單元

1.產 品 資 料 介 紹：

中文資料：

Bailey NTMP01 是一款由 ABB Bailey 生產的終端處理模塊（Terminal Processing Module），常用于 Bailey INFI 90 或 Harmony 控制系統中，作為過程控制系統的一個關鍵組件，用于信號的集中采集、轉換與傳輸。

一、基本信息

二、產品功能特點

1. 過程信號處理功能

   • 連接現場 I/O 信號（如開關量、模擬量）；

   • 實現數據采集、初步轉換、傳輸處理；

   • 支持對多種工業傳感器或執行器的數據接口。

2. 系統接口作用

   • 將現場數據傳送至控制模塊（如 IMMFP12、IMCP01 等）；

   • 支持與 INFI-NET 網絡或系統總線的數據通訊；

   • 可與控制器（如 INICT01）協同工作。

3. 診斷與自監控功能

   • 具有模塊健康狀態指示；

   • 支持熱插拔，便于系統維護與故障替換。

4. 高可靠性設計

   • 工業級溫度范圍與電氣隔離；

   • 抗干擾能力強，適應復雜工控現場環境。

三、技術參數簡要

英文資料：

Bailey NTMP01 is a Terminal Processing Module produced by ABB Bailey, commonly used in Bailey INFI 90 or Harmony control systems as a key component of process control systems for centralized signal acquisition, conversion, and transmission.

1、 Basic Information

Project Description

Product model NTMP01

Manufacturer ABB (formerly Bailey Controls)

Product Name: Terminal Processing Module

System Platform INFI 90/Harmony Control System

Installation method: Plug and unplug installation in the mounting cage

2、 Product functional features

Process signal processing function

Connect on-site I/O signals (such as switch values and analog signals);

Realize data collection, preliminary conversion, transmission and processing;

Support data interfaces for various industrial sensors or actuators.

System interface function

Transfer on-site data to control modules (such as IMMFP12, IMCP01, etc.);

Support data communication with INFI-NET network or system bus;

Can work in conjunction with controllers such as INICT01.

Diagnostic and self-monitoring functions

Has module health status indication;

Support hot plugging for easy system maintenance and fault replacement.

High reliability design

Industrial temperature range and electrical isolation;

Strong anti-interference ability and adaptability to complex industrial control field environments.

3、 Brief Technical Parameters

Project parameters

The power supply voltage is uniformly supplied through the backend module framework (usually+5V or+24V DC)

Interface type Backplane slot connection

Communication methods support expansion such as INFI-NET, MODBUS, serial ports, etc

The working temperature range is usually 0-60 ° C (industry standard)

Module size standard Bailey module size, compatible with Bailey module framework

Applicable systems ABB INFI 90, Harmony, Bailey Net 90 series
