GE IC693MDL655K輸入繼電器
1.產 品 資 料 介 紹：
中文資料：
型號：IC693MDL655K
品牌：GE Fanuc
系列：Series 90-30
類型：數字輸入模塊（繼電器接點型輸入）
技術參數：
輸入點數：16 點
輸入類型：無源干接點輸入（繼電器或機械開關閉合）
電壓范圍：12～24 VDC（推薦 24V）
每點電流：約 7～10 mA
輸入隔離：每 8 點為一組光電隔離
響應時間：小于 10 毫秒
狀態指示：每個輸入點配有 LED 指示燈
通道分組：2 組，每組 8 點，共用一個公共端（COM）
安裝方式：插入式，適用于 90-30 機架槽位
接線說明：
外部信號設備（如按鈕、限位開關）的一端接模塊的某個輸入點。
另一端接外部 24VDC 電源的正極。
外部電源負極接到該組的 COM（公共端）上。
模塊不向輸入設備供電，需外接直流電源。
使用注意事項：
只能接干接點信號，不能接帶電壓的主動信號，否則會損壞模塊。
兩組輸入點的公共端不可混用。
輸入設備必須閉合才能被識別為有效信號。
不適合高速信號采集（如編碼器脈沖輸入）。
典型應用場景：
工業按鈕、限位開關、選擇開關等狀態采集
安全門、急停按鈕、報警觸發等無源輸入信號采集
與輸出模塊配合使用，實現完整的輸入/輸出邏輯控制
英文資料：
Model: IC693MDL655K
Brand: GE Fanuc
Series: Series 90-30
Type: Digital Input Module (Relay Contact Type Input)
Technical parameters:
Input points: 16 points
Input type: Passive dry contact input (relay or mechanical switch closed)
Voltage range: 12-24 VDC (recommended 24V)
Current per point: approximately 7-10 mA
Input isolation: every 8 points is a set of photoelectric isolation
Response time: less than 10 milliseconds
Status indication: Each input point is equipped with LED indicator lights
Channel grouping: 2 groups, each with 8 points, sharing a common terminal (COM)
Installation method: Plug in, suitable for 90-30 rack slots
Wiring instructions:
One end of external signal devices (such as buttons, limit switches) is connected to an input point of the module.
Connect the other end to the positive pole of an external 24VDC power supply.
The negative pole of the external power supply is connected to the COM (common terminal) of the group.
The module does not supply power to the input device and requires an external DC power supply.
Precautions for use:
Only dry contact signals can be connected, and active signals with voltage cannot be connected, otherwise the module will be damaged.
The common terminal of two sets of input points cannot be mixed.
The input device must be closed in order to be recognized as a valid signal.
Not suitable for high-speed signal acquisition (such as encoder pulse input).
Typical application scenarios:
Status acquisition of industrial buttons, limit switches, selection switches, etc
Passive input signal acquisition for safety doors, emergency stop buttons, alarm triggers, etc
Used in conjunction with the output module to achieve complete input/output logic control
2.產 品 展 示
3.其他產品
