ABB 57619414A接口逆變器板
1.產 品 資 料 介 紹：
中文資料：
1. 產品概述
型號標識：57619414A
設備類型：接口逆變器板（Interface Inverter Board）
典型應用：工業變頻器、伺服驅動系統或可再生能源變流器的信號轉換與功率接口
2. 核心功能
信號隔離與轉換：
將控制信號（如PWM）轉換為驅動IGBT/功率模塊的隔離信號
支持高低電平轉換（如3.3V→15V）
故障反饋：
實時監測逆變器狀態（過流、過熱、短路）并反饋至主控單元
通信接口：
可選配RS485、CAN或光纖通信模塊（需確認具體版本）
3. 技術參數
| 參數 | 規格 |
|---|---|
| 輸入電壓 | 24VDC ±10%（控制側） |
| 輸出驅動能力 | 最大2A峰值電流（IGBT驅動） |
| 隔離電壓 | 2500Vrms（輸入/輸出間） |
| 響應時間 | <500ns（故障信號傳輸） |
| 工作溫度 | -20℃ ~ +70℃ |
| 防護等級 | IP20（需安裝于電柜內） |
英文資料：
1. Product Overview
Model identification: 57619414A
Equipment type: Interface Inverter Board
Typical applications: Signal conversion and power interface for industrial frequency converters, servo drive systems, or renewable energy converters
2. Core functions
Signal isolation and conversion:
Convert control signals (such as PWM) into isolation signals that drive IGBT/power modules
Support high and low level conversion (such as 3.3V → 15V)
Fault feedback:
Real time monitoring of inverter status (overcurrent, overheating, short circuit) and feedback to the main control unit
Communication interface:
Optional RS485, CAN or fiber optic communication module (specific version needs to be confirmed)
3. Technical parameters
Parameter specifications
Input voltage 24VDC ± 10% (control side)
Maximum output drive capability 2A peak current (IGBT drive)
Isolation voltage 2500Vrms (between input/output)
Response time<500ns (fault signal transmission)
Working temperature -20 ℃~+70 ℃
Protection level IP20 (to be installed inside the electrical cabinet)
