SANYO DENKI AP-1M100B1C1超級伺服電機

1.產 品 資 料 介 紹：

 SANYO DENKI AP-1M100B1C1超級伺服電機 英文資料：

SANYO DENKI AP-1M100B1C1 is a high-end super servo motor launched by Sanyo Electric. It focuses on ultra precision control and efficient power output, designed specifically for the core driving scenarios of high-end automation equipment, representing Sanyo's advanced technological achievements in the servo field.

In terms of compatibility and collaboration, AP-1M100B1C1 can seamlessly match with the high-end servo drives of the Shanyang Q series, especially when paired with drives with high-speed signal processing capabilities. It can achieve triple precision adjustment of current, speed, and position through closed-loop control, fully unleashing the performance advantages of "super servo".

In terms of core performance, SANYO DENKI AP-1M100B1C1 adopts an embedded permanent magnet rotor design, which has higher mechanical strength and a 20% reduction in rotational inertia compared to traditional models. With optimized electromagnetic circuits, the start-up response time is shortened to less than 5ms, and it can quickly respond to instantaneous load fluctuations.

In terms of precision control, this motor is equipped with a 23 bit high-resolution absolute encoder, with a pulse equivalent of nanometer level. Combined with Shanyang's exclusive error compensation algorithm, the AP-1M100B1C1 achieves a repeat positioning accuracy of ≤± 0.001mm in high-speed positioning tasks, meeting the requirements of high-end scenarios such as semiconductor packaging and precision measurement.

AP-1M100B1C1 has an enhanced protection mechanism, which adds real-time monitoring of rotor temperature and vibration warning function in addition to conventional overcurrent and overload protection. It can predict potential faults 500 hours in advance and minimize equipment shutdown losses.

In terms of structural design, the SANYO DENKI AP-1M100B1C1 adopts a compact body design, which maintains the same size while increasing output power by 30%. The shaft end adopts precision grinding technology and is equipped with a labyrinth sealing structure, with a protection level of IP67, suitable for harsh installation environments with high dust and humidity.

In terms of environmental adaptability, AP-1M100B1C1 breaks through conventional industrial standards, with a working temperature range extended to -20~+65 ℃, a humidity tolerance range of ≤ 95% RH (non condensing), and anti electromagnetic interference performance in accordance with IEC 61800-3 standards. It can operate stably in extreme workshop environments.

In terms of energy consumption performance, SANYO DENKI AP-1M100B1C1 adopts a new type of low iron loss silicon steel sheet and high-efficiency winding design, which improves the comprehensive efficiency to over 96%, saving 15% energy compared to the same power P60 series motor, and reducing the annual operating cost by about 2000 yuan/unit.

In application scenarios, AP-1M100B1C1 is widely used in high-precision scenarios such as semiconductor wafer handling equipment, laser processing machines, and high-end robot joints. With its characteristics of "ultra precision, high speed, and high stability", it has become the core power unit of high-end manufacturing.

 SANYO DENKI AP-1M100B1C1超級伺服電機 產品展示

 產品視頻
