SANYO DENKI PQMOPA16001伺服驅動器
1.產 品 資 料 介 紹：
- SANYO DENKI PQMOPA16001 是中功率伺服驅動器，額定輸出電流 16A，適配 1.5kW-2.5kW 的伺服電機，主打高響應性與穩定驅動，適合中型數控機床進給軸、自動化生產線重型傳動機構等對動力與響應速度有要求的工業場景。
- 6-10 臺該驅動器可通過 EtherCAT 工業總線實現高速協同控制，驅動生產線多軸聯動部件，比如新能源電池極片裁切機的多軸送料機構，能同步各軸送料速度與裁切節奏，確保極片尺寸公差控制在 ±0.02mm 內，提升裁切合格率至 99.5% 以上。
- 適配三相 200V-230V 工業標準電源，輸入電壓波動允許范圍 ±15%（170V-265V），可適應工廠供電電壓的較大波動，無需額外配置穩壓設備，降低復雜供電環境下的設備部署成本。
- 采用壁掛式 + 模塊化設計，核心驅動單元與控制單元獨立封裝，后期維護時可單獨拆卸更換故障單元，無需整體拆解驅動器，維修時間縮短至 20 分鐘以內，減少生產線停機損失。
- 能與同品牌 P 系列中功率伺服電機（如 P60B13200HBV00）無縫兼容，支持 “電機參數自動讀取” 功能，通電后可自動識別電機型號并加載匹配參數，避免人工設置誤差，調試效率提升 50% 以上。
- 支持位置、速度、扭矩、轉矩限制四種控制模式，位置控制時脈沖響應頻率達 1MHz，配合高精度電子凸輪功能，可實現復雜軌跡運動控制，滿足異形零件加工時的曲線進給需求。
- 內置過流、過壓、過載、欠壓、過熱、編碼器故障六種保護功能，故障發生時會立即切斷輸出并觸發聲光報警，同時將故障信息存儲至本地內存，工作人員通過配套診斷軟件可回溯故障前 30 秒運行數據，快速定位問題根源。
- 搭載 “能量回饋” 技術，電機減速或制動時產生的再生電能可高效回饋至電網，相比傳統驅動器能耗降低 20%-25%，10 臺批量使用時，每年可幫助企業節省約 3500 度電，符合工業節能降耗要求。
- 配備 5 英寸彩色觸控屏，可實時顯示電機轉速、電流、位置、故障代碼等 20 + 項運行參數，支持自定義參數顯示界面，同時具備參數加密功能，防止非授權人員誤修改關鍵設置，保障設備運行穩定性。
- 整體在高響應控制、兼容性與節能性上表現突出，無論是單臺驅動中型加工設備，還是 10 臺左右批量部署于重型自動化生產線，都能為伺服系統提供高效可靠的驅動支持。
SANYO DENKI PQMOPA16001伺服驅動器 英文資料：
SANYO DENKI PQMOPA16001 is a medium power servo drive with a rated output current of 16A, suitable for servo motors ranging from 1.5kW to 2.5kW. It focuses on high responsiveness and stable driving, and is suitable for industrial scenarios such as feed shafts for medium-sized CNC machine tools and heavy-duty transmission mechanisms for automated production lines that require power and response speed.
6-10 units of this driver can achieve high-speed collaborative control through EtherCAT industrial bus, driving multi axis linkage components of the production line, such as the multi axis feeding mechanism of the new energy battery electrode cutting machine, which can synchronize the feeding speed and cutting rhythm of each axis, ensuring that the electrode size tolerance is controlled within ± 0.02mm, and improving the cutting pass rate to over 99.5%.
Suitable for three-phase 200V-230V industrial standard power supply, with an allowable range of input voltage fluctuation of ± 15% (170V-265V), it can adapt to large fluctuations in factory power supply voltage without the need for additional voltage stabilization equipment, reducing equipment deployment costs in complex power supply environments.
Adopting wall mounted and modular design, the core drive unit and control unit are independently packaged. During later maintenance, the faulty unit can be disassembled and replaced separately, without the need to disassemble the driver as a whole. The repair time is shortened to less than 20 minutes, reducing production line downtime losses.
It is seamlessly compatible with power servo motors of the same brand P series (such as P60B13200HV00), supports the "automatic reading of motor parameters" function, and can automatically identify the motor model and load matching parameters after power on, avoiding manual setting errors and improving debugging efficiency by more than 50%.
Supports four control modes: position, speed, torque, and torque limit. The pulse response frequency during position control reaches 1MHz. Combined with high-precision electronic cam function, it can achieve complex trajectory motion control and meet the curve feed requirements during the processing of irregular parts.
Built in six protection functions: overcurrent, overvoltage, overload, undervoltage, overheating, and encoder failure. When a fault occurs, the output will be immediately cut off and an audible and visual alarm will be triggered. At the same time, the fault information will be stored in local memory. The staff can trace the operating data of the previous 30 seconds through the supporting diagnostic software to quickly locate the root cause of the problem.
Equipped with "energy feedback" technology, the regenerated electricity generated during motor deceleration or braking can be efficiently fed back to the power grid, reducing energy consumption by 20% -25% compared to traditional drives. When 10 units are used in bulk, it can help enterprises save about 3500 kWh of electricity per year, which meets the requirements of industrial energy conservation and consumption reduction.
Equipped with a 5-inch color touch screen, it can display more than 20 operating parameters such as motor speed, current, position, and fault codes in real time. It supports custom parameter display interface and also has parameter encryption function to prevent unauthorized personnel from accidentally modifying key settings, ensuring the stability of equipment operation.
The overall performance is outstanding in high response control, compatibility, and energy efficiency. Whether it is a single drive medium-sized processing equipment or a batch deployment of about 10 units on heavy-duty automated production lines, it can provide efficient and reliable drive support for servo systems.
SANYO DENKI PQMOPA16001伺服驅動器 產品展示
產品視頻
