SANYO DENKI P60B13200HBV00交流電伺服電機
1.產 品 資 料 介 紹：
- SANYO DENKI P60B13200HBV00 是中功率交流電伺服電機，額定功率 2.0kW、額定轉速 2000rpm，扭矩輸出達 9.55N?m，動力強勁且穩定，適合中型數控機床主軸、自動化生產線重型傳動機構等對動力要求較高的工業場景。
- 5-8 臺該電機可通過工業總線實現協同控制，驅動生產線多工位重型執行部件，比如汽車底盤焊接線的翻轉機構，能精準同步各翻轉單元的轉速與角度，確保焊接點位精準對齊，提升焊接合格率至 99% 以上。
- 適配三相 200V-230V 工業標準電源，電源接口采用防誤插卡扣設計，可直接接入工廠現有供電回路，輸入電壓波動允許范圍 ±10%，能適應車間供電電壓的輕微波動，無需額外配置穩壓設備。
- 采用軸徑 28mm 的加粗輸出軸設計，軸端硬度達 HRC55，抗磨損與抗沖擊能力強，可直接適配大負載聯軸器或齒輪箱，無需額外加固軸端，適配重型傳動系統的使用需求。
- 能與同品牌 60 系列伺服放大器（如 60BA150VFW00）快速兼容，通過放大器的 “電機自動識別” 功能，可一鍵讀取電機參數并完成校準，避免人工調試誤差，調試時間縮短至 30 分鐘以內。
- 內置 2500 線高精度增量式編碼器，配合放大器的高頻采樣技術（采樣頻率 1MHz），可實時捕捉電機轉速與位置變化，位置控制重復精度達 ±0.005mm，滿足精密加工設備對定位精度的嚴苛需求。
- 優化的轉子磁路設計降低了轉動慣量，電機啟停響應速度快，從靜止到額定轉速的啟動時間僅需 0.25 秒，適合需要頻繁切換運行狀態的間歇式生產場景，如數控機床的快速換刀工序。
- 機身防護等級達 IP54，外殼接縫處采用耐油丁腈橡膠密封，輸出軸端配備雙唇密封圈，能有效阻擋車間粉塵、切削液與潤滑油的侵入，適應機械加工車間多油污、多粉塵的復雜環境。
- 定子繞組選用 H 級耐高溫漆包線，配合內置溫度傳感器的過熱保護功能，當繞組溫度超過 155℃時自動觸發保護，避免因過熱導致電機燒毀，延長電機使用壽命至 12000 小時以上。
- 整體在高功率輸出、精準控制與耐用性上表現突出，無論是單臺用于中型加工設備主軸，還是 8 臺左右批量部署于重型自動化生產線，都能為工業自動化生產提供持續可靠的動力支持。
SANYO DENKI P60B13200HBV00交流電伺服電機 英文資料：
SANYO DENKI P60B13200HBV00 is a medium power AC servo motor with a rated power of 2.0kW, a rated speed of 2000rpm, and a torque output of 9.55N · m. It has strong and stable power and is suitable for industrial scenarios with high power requirements such as medium-sized CNC machine tool spindles and heavy-duty transmission mechanisms in automated production lines.
5-8 of these motors can be collaboratively controlled through an industrial bus to drive heavy-duty execution components at multiple workstations on a production line, such as the flipping mechanism of an automotive chassis welding line. They can accurately synchronize the speed and angle of each flipping unit, ensuring precise alignment of welding points and improving the welding qualification rate to over 99%.
Compatible with three-phase 200V-230V industrial standard power supply, the power interface adopts anti misoperation card buckle design, which can be directly connected to the existing power supply circuit of the factory. The allowable range of input voltage fluctuation is ± 10%, which can adapt to slight fluctuations in the workshop power supply voltage without the need for additional voltage stabilization equipment.
Adopting a thickened output shaft design with a diameter of 28mm, the shaft end hardness reaches HRC55, with strong wear and impact resistance, and can be directly adapted to large load couplings or gearboxes without the need for additional reinforcement of the shaft end, meeting the needs of heavy-duty transmission systems.
It can be quickly compatible with 60 series servo amplifiers of the same brand (such as 60BA150VFW00). Through the amplifier's "motor automatic recognition" function, motor parameters can be read and calibrated with one click, avoiding manual debugging errors and shortening debugging time to less than 30 minutes.
Built in 2500 line high-precision incremental encoder, combined with high-frequency sampling technology of amplifier (sampling frequency 1MHz), can capture motor speed and position changes in real time, with a position control repeatability of ± 0.005mm, meeting the strict requirements of precision machining equipment for positioning accuracy.
The optimized rotor magnetic circuit design reduces the moment of inertia, and the motor has a fast start stop response speed. The start-up time from static to rated speed only takes 0.25 seconds, making it suitable for intermittent production scenarios that require frequent switching of operating states, such as the fast tool changing process of CNC machine tools.
The body protection level reaches IP54, and the joint of the shell is sealed with oil resistant nitrile rubber. The output shaft end is equipped with a double lip sealing ring, which can effectively block the invasion of workshop dust, cutting fluid and lubricating oil, and adapt to the complex environment of mechanical processing workshop with multiple oil stains and dust.
The stator winding uses H-grade high-temperature resistant enameled wire, combined with the built-in temperature sensor's overheat protection function. When the winding temperature exceeds 155 ℃, the protection is automatically triggered to avoid motor burnout caused by overheating and extend the motor's service life to more than 12000 hours.
The overall performance is outstanding in high power output, precise control, and durability. Whether it is a single spindle used for medium-sized processing equipment or a batch deployment of about 8 on heavy-duty automation production lines, it can provide continuous and reliable power support for industrial automation production.
SANYO DENKI P60B13200HBV00交流電伺服電機 產品展示
