SANYO DENKI 60BA150VFW00伺服放大器
1.產 品 資 料 介 紹：
- SANYO DENKI 60BA150VFW00 是中功率伺服放大器，額定輸出電流 15A，適配 1.5kW-2.0kW 的伺服電機，主打高精度驅動控制，適合中型數控機床、自動化裝配線等對動力與精度均有要求的工業場景。
- 5-10 臺該放大器可通過 Profinet 工業總線實現協同控制，驅動生產線多臺電機同步運行，比如電子元件插件線的多軸傳動機構，能精準同步各軸轉速，避免元件插件時出現錯位，提升插件合格率。
- 適配三相 200V-230V 工業標準電源，輸入電壓波動允許范圍 ±10%，可適應工廠供電電壓的輕微波動，無需額外配置穩壓設備，降低電路部署成本與復雜度。
- 采用模塊化設計，功率單元與控制單元獨立布局，后期維護時可單獨更換故障模塊，無需整體更換放大器，大幅降低維修成本與停機時間。
- 能與同品牌 60 系列伺服電機（如 P60B13150HXSOO）快速兼容，通過 “電機自動識別” 功能，可一鍵讀取電機參數并完成校準，避免人工設置參數的誤差，縮短調試周期。
- 支持位置、速度、扭矩三種控制模式，可通過面板按鍵或上位機軟件切換，位置控制時脈沖響應頻率達 500kHz，能滿足精密加工設備對高頻定位指令的響應需求。
- 內置過流、過壓、過載、過熱四重保護功能，當檢測到異常工況時，會立即切斷輸出并觸發報警，同時保存故障代碼，便于工作人員快速定位問題，保障設備與人員安全。
- 優化的散熱系統，機身背部設有大面積散熱片，配合靜音風扇的智能調速（根據溫度自動調節轉速），24 小時連續運行時機身溫度可控制在 65℃以下，避免高溫影響控制精度。
- 具備 “能耗回饋” 功能，電機減速或制動時產生的電能可回饋至電網，相比傳統放大器能降低 15%-20% 的能耗，長期批量使用（如 10 臺）可幫助企業節省可觀的電費成本。
- 整體在控制精度、兼容性與節能性上表現突出，無論是單臺驅動中型加工設備電機，還是 10 臺左右批量部署于自動化生產線，都能為伺服系統提供穩定可靠的驅動支持。
SANYO DENKI 60BA150VFW00伺服放大器 英文資料：
SANYO DENKI 60BA150VFW00 is a medium power servo amplifier with a rated output current of 15A. It is compatible with servo motors ranging from 1.5kW to 2.0kW and focuses on high-precision drive control. It is suitable for industrial scenarios such as medium-sized CNC machine tools and automated assembly lines that require both power and accuracy.
5-10 units of this amplifier can achieve collaborative control through Profinet industrial bus, driving multiple motors on the production line to operate synchronously. For example, the multi axis transmission mechanism of the electronic component plug-in line can accurately synchronize the speed of each axis, avoiding misalignment during component insertion and improving the qualification rate of the plug-in.
Suitable for three-phase 200V-230V industrial standard power supply, with an allowable range of input voltage fluctuation of ± 10%. It can adapt to slight fluctuations in factory power supply voltage without the need for additional voltage stabilization equipment, reducing circuit deployment costs and complexity.
Adopting modular design, the power unit and control unit are independently arranged, and the faulty module can be replaced separately during later maintenance without the need to ｒｅｐｌａｃｅ the amplifier as a whole, greatly reducing maintenance costs and downtime.
It can be quickly compatible with 60 series servo motors of the same brand (such as P60B13150HXSOO). Through the "motor automatic recognition" function, the motor parameters can be read and calibrated with one click, avoiding errors in manual parameter settings and shortening the debugging cycle.
Supports three control modes: position, speed, and torque, which can be switched through panel buttons or upper computer software. The pulse response frequency during position control reaches 500kHz, which can meet the response requirements of precision machining equipment for high-frequency positioning commands.
Built in overcurrent, overvoltage, overload, and overheating protection functions. When abnormal working conditions are detected, the output will be immediately cut off and an alarm will be triggered. At the same time, the fault code will be saved for staff to quickly locate the problem and ensure the safety of equipment and personnel.
Optimized heat dissipation system, equipped with large area heat sinks on the back of the body, coupled with intelligent speed regulation of the silent fan (automatically adjusting the speed according to temperature), the body temperature can be controlled below 65 ℃ during 24-hour continuous operation, avoiding high temperature affecting control accuracy.
Equipped with the "energy consumption feedback" function, the electrical energy generated during motor deceleration or braking can be fed back to the grid, reducing energy consumption by 15% -20% compared to traditional amplifiers. Long term batch use (such as 10 units) can help enterprises save considerable electricity costs.
The overall performance is outstanding in terms of control accuracy, compatibility, and energy efficiency. Whether it is a single drive for medium-sized machining equipment motors or about 10 units deployed in batches on automated production lines, it can provide stable and reliable drive support for servo systems.
SANYO DENKI 60BA150VFW00伺服放大器 產品展示
產品視頻
