SANYO DENKI P60B18550RBV0千瓦制動器
1.產 品 資 料 介 紹：
- SANYO DENKI P60B18550RBV0 是帶電磁制動器的中功率交流電伺服電機，額定功率 5.5kW、額定轉速 1500rpm，兼具強勁動力與制動鎖止功能，適合重型輸送線、升降式加工設備等需緊急停駐的場景。
- 4-8 臺該電機可通過總線協同控制，驅動重型生產線的傳動系統，比如汽車底盤裝配線的升降平臺，制動響應時間≤0.1 秒，能在斷電或緊急停機時快速鎖止電機軸，避免設備滑行風險。
- 適配三相 380V 工業標準電源，制動器供電為 DC24V，可直接接入工廠高壓供電回路與低壓控制回路，無需額外配置電源轉換模塊，降低電路部署復雜度。
- 采用大扭矩電磁制動器設計，制動扭矩達 25N?m，電機停機后能穩定鎖止負載，即使在傾斜 30° 的輸送軌道上，也可防止物料滑落，提升設備運行安全性。
- 能與同品牌 60 系列伺服驅動器（如 60BB075FXW14）快速匹配，通過驅動器參數設置可調節制動延時與釋放時序，適配不同負載的啟停需求，縮短調試周期。
- 內置 2500 線高精度增量式編碼器，配合制動器的精準鎖止，可實現 “驅動 - 定位 - 制動” 一體化控制，位置重復精度達 ±0.005mm，滿足重型精密加工的定位需求。
- 制動器采用常閉設計，斷電后自動抱閘鎖止，通電后 0.05 秒內釋放，適配間歇式生產場景，比如數控機床換刀機構，可在換刀過程中穩定鎖止電機軸，避免刀架偏移。
- 機身采用 IP54 防護等級，制動器外殼額外做密封處理，能抵御車間粉塵、切削液飛濺，即使在機械加工車間的潮濕油污環境中，也可保障制動組件的使用壽命。
- 定子繞組采用 H 級耐高溫漆包線，長期運行時繞組溫度穩定在 90℃以下，制動器線圈散熱結構優化，連續制動 10 次后溫度不超過 60℃，適配高頻啟停的重型工況。
- 整體在高功率輸出、安全制動、精密定位上表現突出，無論是單臺用于重型升降設備，還是多臺批量部署于重型生產線，都能為工業自動化提供可靠的動力與安全保障。
SANYO DENKI P60B18550RBV0千瓦制動器 英文資料：
SANYO DENKI P60B18550RBV0 is a medium power AC servo motor with an electromagnetic brake. It has a rated power of 5.5kW and a rated speed of 1500rpm, and combines strong power and braking locking function. It is suitable for emergency parking scenarios such as heavy-duty conveyor lines and lifting processing equipment.
4-8 of these motors can be controlled through bus coordination to drive the transmission system of heavy-duty production lines, such as the lifting platform of automotive chassis assembly lines. The braking response time is ≤ 0.1 seconds, and the motor shaft can be quickly locked in case of power failure or emergency stop, avoiding the risk of equipment sliding.
Compatible with three-phase 380V industrial standard power supply, the brake power supply is DC24V, which can be directly connected to the factory's high-voltage power supply circuit and low-voltage control circuit without the need for additional power conversion modules, reducing the complexity of circuit deployment.
Adopting a high torque electromagnetic brake design, the braking torque reaches 25N · m, and the motor can stably lock the load after stopping. Even on a tilted 30 ° conveyor track, it can prevent material from slipping and improve the safety of equipment operation.
It can quickly match with 60 series servo drives of the same brand (such as 60BB075FXW14), adjust the braking delay and release timing through driver parameter settings, adapt to the start stop requirements of different loads, and shorten the debugging cycle.
Built in 2500 line high-precision incremental encoder, coupled with precise locking of the brake, can achieve integrated control of "drive positioning brake", with a position repetition accuracy of ± 0.005mm, meeting the positioning requirements of heavy-duty precision machining.
The brake adopts a normally closed design, which automatically locks the brake after power failure and releases within 0.05 seconds after power on. It is suitable for intermittent production scenarios, such as the tool changing mechanism of CNC machine tools, which can stably lock the motor shaft during the tool changing process and avoid tool holder deviation.
The body adopts IP54 protection level, and the brake housing is additionally sealed to resist workshop dust and cutting fluid splashes. Even in the humid and oily environment of the machining workshop, the service life of the brake components can be guaranteed.
The stator winding adopts H-grade high-temperature resistant enameled wire, and the winding temperature remains stable below 90 ℃ during long-term operation. The heat dissipation structure of the brake coil is optimized, and the temperature does not exceed 60 ℃ after 10 consecutive braking cycles, suitable for high-frequency start stop heavy-duty working conditions.
Overall, it performs outstandingly in high power output, safe braking, and precise positioning. Whether used alone for heavy-duty lifting equipment or deployed in batches on heavy-duty production lines, it can provide reliable power and safety guarantees for industrial automation.
SANYO DENKI P60B18550RBV0千瓦制動器 產品展示
