TRICONEX 3805E模擬輸出模塊
1.產 品 資 料 介 紹：
- 高精度模擬輸出：每路輸出精度達 ±0.1%，支持 4-20mA/0-10V 標準模擬信號，能精準控制閥門開度、電機轉速等，滿足化工、核電等精密調控需求。
- 多通道獨立控制：集成 8 路獨立模擬輸出通道，每路可單獨配置參數，不用共享資源，能同時驅動多個執行器，適配多設備協同控制場景。
- 三重冗余保安全：沿用 TMR 架構，三個通道同步輸出并互校，單個通道故障不影響信號穩定性，符合 SIL 3 安全標準，高危環境也能放心用。
- 快速信號響應：輸出信號切換延遲低至 5ms，參數調整后能迅速反饋到執行端，比普通模塊響應快 30%，適合對時效性要求高的調控場景。
- 自帶保護功能：每路具備過流、短路保護，不用外接保護元件，故障時自動切斷該路輸出，避免損壞設備，降低維護成本。
- 抗干擾能力強：信號通道與背板間 1500V DC 隔離，能抵御電磁輻射、電網波動，在變頻器密集車間，輸出信號波動仍小于 ±0.05%。
- 寬溫環境適配：工作溫度覆蓋 - 40℃至 70℃，電路板做防潮涂層，高濕度、多粉塵環境下也能穩定運行，不用額外裝溫控或防塵設備。
- 支持在線維護：可帶電插拔，系統運行時能更換模塊或校準輸出參數，不用停線，維護過程不影響生產，提升設備利用率。
- 靈活對接系統：無縫兼容 TRICONEX TMR 安全控制系統，支持 Modbus TCP 協議，和 PLC、監控平臺連接簡單，不用大量修改程序。
- 高耐用設計：外殼用防腐蝕金屬材質，關鍵元器件選工業級產品，平均無故障工作時間超 15 萬小時，適合長期連續運行場景。
TRICONEX 3805E模擬輸出模塊 英文資料：
High precision analog output: Each output has an accuracy of ± 0.1%, supports 4-20mA/0-10V standard analog signals, and can accurately control valve opening, motor speed, etc., meeting the precision control needs of chemical, nuclear and other industries.
Multi channel independent control: integrates 8 independent analog output channels, each of which can be individually configured with parameters without sharing resources. It can simultaneously drive multiple actuators and adapt to multi device collaborative control scenarios.
Triple redundancy ensures safety: using TMR architecture, three channels output synchronously and calibrate each other, and a single channel failure does not affect signal stability. It meets SIL 3 safety standards and can be used with confidence in high-risk environments.
Fast signal response: The output signal switching delay is as low as 5ms, and after parameter adjustment, it can quickly feedback to the execution end, which is 30% faster than the response of ordinary modules. It is suitable for control scenarios with high timeliness requirements.
Self protective function: Each circuit is equipped with overcurrent and short-circuit protection, without the need for external protective components. In case of a fault, the output of the circuit will be automatically cut off to avoid damaging the equipment and reduce maintenance costs.
Strong anti-interference ability: The signal channel is isolated from the backplane at 1500V DC, which can resist electromagnetic radiation and power grid fluctuations. In a workshop with dense frequency converters, the output signal fluctuation is still less than ± 0.05%.
Wide temperature environment adaptation: The working temperature covers -40 ℃ to 70 ℃, and the circuit board is coated with moisture-proof material. It can operate stably even in high humidity and dusty environments without the need for additional temperature control or dust prevention equipment.
Support online maintenance: It can be plugged and unplugged with power, and modules can be replaced or output parameters can be calibrated during system operation without stopping the line. The maintenance process does not affect production and improves equipment utilization.
Flexible docking system: seamlessly compatible with TRICONEX TMR safety control system, supporting Modbus TCP protocol, easy to connect with PLC and monitoring platform, without extensive program modification.
High durability design: The casing is made of corrosion-resistant metal material, and key components are selected from industrial grade products. The average time between failures exceeds 150000 hours, making it suitable for long-term continuous operation scenarios.
TRICONEX 3805E模擬輸出模塊 產品展示
