Extreme Networks HM-2X24GA端口托管千兆交換機
1.產 品 資 料 介 紹:
- 雙區 48 口千兆電口配置:Extreme Networks HM-2X24GA 采用 “2 組 24 口” 分區設計,共配備 48 個 10/100/1000Base-T 自適應千兆電口,每組 24 口可獨立劃分網絡區域(如辦公區與監控區),適配企業多業務場景的終端分類接入需求,兼顧高密度連接與網絡分區管理靈活性。
- 靈活上行擴展能力:推測配備 2-4 個 SFP 千兆光口(參考同系列托管機型),支持多模 / 單模光纖模塊接入,可實現跨樓層、長距離核心網絡互聯,同時支持鏈路聚合(LAG)功能,通過綁定多上行鏈路提升帶寬與冗余,避免單點鏈路故障導致的網絡中斷。
- 全端口線速轉發性能:采用非阻塞交換架構,交換容量預計達 100Gbps 以上,轉發速率超 74Mpps,所有 48 個千兆電口與上行光口均支持線速處理,確保多終端并發傳輸(如 4K 視頻監控、大規模辦公數據交互)無瓶頸,滿足企業級低延遲業務需求。
- 托管級多層網絡功能:作為托管型交換機,支持完整二層特性與基礎三層功能 —— 二層側兼容 IEEE 802.1q VLAN(支持 4096 個 VLAN)、802.3ad 鏈路聚合、STP/RSTP/MSTP 生成樹;三層側支持靜態路由與 RIP v1/v2 動態路由,可實現跨網段通信與路由優化,適配中小型企業多層網絡架構。
- 多維度智能管理體系:支持三重管理方式 ——Web 圖形化管理界面(直觀配置 VLAN、QoS 等功能,適配新手運維)、CLI 命令行(滿足高級用戶精細化配置需求)、SNMP v3 協議(兼容第三方網絡管理平臺集中管控),同時支持零配置啟動(ZTP),新設備通電即可自動獲取配置,簡化部署流程。
- 精細化 QoS 流量管控:支持基于端口、802.1p 優先級、DSCP 值的流量分類與調度,可劃分 8 個優先級隊列,為語音通話、視頻會議等實時業務分配專屬帶寬,限制非關鍵數據(如下載、P2P)的帶寬占用,避免網絡擁塞導致的業務卡頓,保障核心業務傳輸質量。
Extreme Networks HM-2X24GA端口托管千兆交換機 英文資料:
Dual zone 48 port Gigabit Ethernet configuration: The Extreme Networks HM-2X24GA adopts a "2-group 24 port" partition design, equipped with a total of 48 10/100/1000Base-T adaptive Gigabit Ethernet ports. Each group of 24 ports can be independently divided into network areas (such as office and monitoring areas), adapting to the terminal classification access needs of multiple business scenarios in enterprises, and balancing high-density connectivity and network partition management flexibility.
Flexible uplink expansion capability: It is speculated to be equipped with 2-4 SFP gigabit optical ports (referring to the same series of hosting models), supporting multi-mode/single-mode fiber module access, which can achieve cross floor and long-distance core network interconnection. At the same time, it supports link aggregation (LAG) function, which improves bandwidth and redundancy by binding multiple uplink links, avoiding network interruption caused by single point link failures.
Full port line speed forwarding performance: Adopting a non blocking switching architecture, the expected switching capacity is over 100Gbps, with a forwarding rate of over 74Mpps. All 48 gigabit electrical ports and upstream optical ports support line speed processing, ensuring seamless concurrent transmission of multiple terminals (such as 4K video surveillance and large-scale office data exchange) and meeting enterprise level low latency business requirements.
Managed multi-layer network function: As a managed switch, it supports complete layer 2 features and basic layer 3 functions - layer 2 is compatible with IEEE 802.1q VLAN (supporting 4096 VLANs), 802.3ad link aggregation, STP/RSTP/MSTP spanning tree; The three-layer side supports static routing and RIP v1/v2 dynamic routing, enabling cross segment communication and routing optimization, and adapting to multi-layer network architectures for small and medium-sized enterprises.
Multi dimensional intelligent management system: supports triple management methods - Web graphical management interface (intuitive configuration of VLAN, QoS and other functions, suitable for novice operation and maintenance), CLI command line (meeting the refined configuration needs of advanced users), SNMP v3 protocol (compatible with centralized control of third-party network management platforms), and zero configuration boot (ZTP). New devices can automatically obtain configurations when powered on, simplifying the deployment process.
Fine tuned QoS traffic control: supports traffic classification and scheduling based on ports, 802.1p priority, and DSCP values, and can be divided into 8 priority queues to allocate dedicated bandwidth for real-time services such as voice calls and video conferences. It limits the bandwidth occupation of non critical data (such as downloads and P2P), avoids business lag caused by network congestion, and ensures the transmission quality of core services.
Extreme Networks HM-2X24GA端口托管千兆交換機 產品展示

產品視頻
