MOOG G631-3004B伺服閥
1.產 品 資 料 介 紹：
- 直動式伺服控制架構：MOOG G631-3004B 采用直動式（DDV）設計，通過永磁式線性力馬達直接驅動閥芯運動，省去傳統先導級結構，減少液壓油流阻與響應滯后，結構更緊湊的同時提升控制靈敏度，適配對空間與動態性能要求嚴苛的工業場景。
- 一體化電反饋設計：內置高精度閥芯位置傳感器與閉環控制電路，可實時采集閥芯位移信號并反饋至控制模塊，形成精準的位置閉環控制，配合線性力馬達的穩定驅動力，有效降低外部干擾對控制精度的影響，保障輸出流量的一致性。
- 抗污染液壓設計：閥芯與閥套采用間隙密封結構，且表面經特殊硬化處理（如氮化或鍍鉻工藝），提升耐磨性與抗腐蝕能力，可耐受液壓油中一定程度的雜質污染，減少因油液清潔度不足導致的閥芯卡滯故障，適配液壓系統維護周期較長的場景。
- 寬量程壓力適配能力：最大工作壓力可達 31.5MPa，可適配中高壓液壓系統需求，在 5-31.5MPa 壓力范圍內均能保持穩定的流量輸出，既能滿足小型精密設備的低壓控制需求，也可適配中型工業機械的中高壓動力供給場景。
- 高效動態響應特性：頻率響應可達 80-120Hz（±100% 輸入信號），階躍響應時間≤12ms，能快速跟隨輸入信號的動態變化調整流量輸出，有效抑制液壓系統的動態滯后，保障高速運動執行機構（如精密機床主軸、測試臺作動器）的控制穩定性。
- 超高控制精度指標：滯環誤差≤0.2%，分辨率低于 0.1%，流量重復精度優于 0.3%，在全流量范圍內（通常覆蓋 2-50L/min，具體視工況）可實現流量的精細化調節，即便在低流量微調場景（如壓力閉環控制），也能保持輸出的高穩定性。
MOOG G631-3004B伺服閥 英文資料：
1、 Infrastructure and Design Characteristics
Direct acting servo control architecture: MOOG G631-3004B adopts a direct acting (DDV) design, which directly drives the valve core movement through a permanent magnet linear force motor, eliminating the traditional pilot stage structure, reducing hydraulic oil flow resistance and response lag, and improving control sensitivity while making the structure more compact. It is suitable for industrial scenarios with strict requirements for space and dynamic performance.
Integrated electric feedback design: Equipped with a high-precision valve core position sensor and closed-loop control circuit, it can collect real-time valve core displacement signals and feedback them to the control module, forming accurate position closed-loop control. Combined with the stable driving force of the linear force motor, it effectively reduces the impact of external interference on control accuracy and ensures the consistency of output flow.
Anti pollution hydraulic design: The valve core and valve sleeve adopt a gap sealing structure, and the surface is specially hardened (such as nitriding or chrome plating process) to improve wear resistance and corrosion resistance. It can withstand a certain degree of impurity pollution in hydraulic oil, reduce valve core sticking faults caused by insufficient oil cleanliness, and adapt to scenarios with long maintenance cycles in hydraulic systems.
2、 Core performance and control accuracy
Wide range pressure adaptation capability: The maximum working pressure can reach 31.5MPa, which can adapt to the requirements of medium and high pressure hydraulic systems. It can maintain stable flow output within the pressure range of 5-31.5MPa, which can meet the low-pressure control needs of small precision equipment and also adapt to the medium and high pressure power supply scenarios of medium-sized industrial machinery.
Efficient dynamic response characteristics: The frequency response can reach 80-120Hz (± 100% input signal), and the step response time is ≤ 12ms. It can quickly follow the dynamic changes of the input signal to adjust the flow output, effectively suppressing the dynamic lag of the hydraulic system and ensuring the control stability of high-speed motion actuators (such as precision machine tool spindles and test bench actuators).
Ultra high control accuracy indicators: hysteresis error ≤ 0.2%, resolution below 0.1%, flow repeatability accuracy better than 0.3%. Fine flow adjustment can be achieved within the full flow range (usually covering 2-50L/min, depending on the operating conditions), and even in low flow fine-tuning scenarios (such as pressure closed-loop control), high output stability can be maintained.
