AMAT Applied Materials 0500-01065 接口模塊
1.產 品 資 料 介 紹：
核心規格
功能特點
典型應用
AMAT Applied Materials 0500-01065 接口模塊 英文資料：
AMAT Applied Materials 0500-01065 is a 300 mm wafer load lock interface module PCB used to connect machine control systems with mechanical/pneumatic components, achieve signal conversion, isolation, and distribution, and is compatible with multiple generations of 300 mm platforms.
Core specifications
Project specification remarks
Application Series: Buffer Chamber for 300mm Load Lock Wafer Entry and Exit Equipment
Functional signal conversion and isolation control, sensors, pneumatic valves, etc
Interface type: high-density needle socket, connector (Phoenix/TE) compatible with backplate and field devices
Working voltage 5-24 VDC (multi rail) supports mixed voltage distribution
Isolation method: photoelectric isolation+electrical isolation. Each circuit is independent and has strong anti-interference ability
Installation method: panel type/rail type standard cabinet adaptation
Size 160 × 100 × 40 mm (approximately) Compact design
Protection level IP20 dustproof and splash proof
Features
Multi protocol compatibility: can adapt to different brands of PLCs/controllers, with strong universality.
Modular channel: The channel can be flexibly configured for easy expansion and maintenance.
Status visualization: Each channel is equipped with LED indicator lights to display the working status in real-time.
Hot swappable design: ｒｅｐｌａｃｅ modules with power on to reduce downtime.
Low noise design: multi-layer PCB+shielding design to suppress crosstalk and noise interference.
Typical Applications
300 mm wafer load lock chamber control and status monitoring
Signal distribution for semiconductor equipment wafer transmission system
Signal conversion between sensors and actuators in industrial automation
AMAT Applied Materials 0500-01065 接口模塊 產品展示
產品視頻
