AMAT Applied Materials  03-81723-00電機驅動器總成模塊

1.產 品 資 料 介 紹：

產品應用領域

1. 半導體制造設備運動控制

   • 應用于 AMAT 的沉積（CVD、PVD）、刻蝕、離子注入等工藝設備。

   • 負責驅動設備內部的電機，完成精準的機械運動控制。

2. 晶圓搬運與傳輸系統

   • 在晶圓由加載端到工藝腔體、再到卸載端的傳輸過程中，電機驅動器控制搬運機械臂的旋轉、升降與抓取動作。

   • 保證晶圓在真空腔體或大氣環境中穩定、無顆粒污染地傳輸。

3. 閥門與真空腔門的啟閉控制

   • 用于驅動腔體的開關閥門、滑板門（Slit Valve）等機械部件。

   • 確保腔體之間真空隔離或工藝切換時的高可靠啟閉動作。

4. 晶圓對準與旋轉系統

   • 應用于晶圓定向器（Orienter）和旋轉臺，幫助晶圓在工藝前進行方向和位置的精確對準。

5. 載片盒與工藝托盤機構

   • 控制晶圓載片盒的進出、定位和搬運。

   • 驅動器為托盤、夾具等部件提供運動動力，實現自動化裝卸片功能。

AMAT Applied Materials 03-81723-00電機驅動器總成模塊 英文資料：

Product application areas

Motion Control of Semiconductor Manufacturing Equipment

Applied to AMAT's deposition (CVD, PVD), etching, ion implantation and other process equipment.

Responsible for driving the internal motors of the equipment and achieving precise mechanical motion control.

Wafer Handling and Transport System

During the transfer of wafers from the loading end to the process chamber and then to the unloading end, the motor driver controls the rotation, lifting, and gripping actions of the handling robotic arm.

Ensure stable and particle free transfer of wafers in vacuum chambers or atmospheric environments.

Opening and closing control of valves and vacuum chamber doors

Mechanical components such as switch valves and slide valves used to drive the chamber.

Ensure highly reliable opening and closing actions during vacuum isolation or process switching between chambers.

Wafer Alignment and Rotation System

Applied to wafer orienters and rotary tables, it helps to accurately align the direction and position of wafers before processing.

Carrier box and process tray mechanism

Control the entry, exit, positioning, and handling of wafer carriers.

The driver provides motion power for components such as trays and fixtures, achieving automated loading and unloading functions.

AMAT Applied Materials 03-81723-00電機驅動器總成模塊 產品展示

 產品視頻
