Extreme Networks SK8009-1224-F8交換機
1.產 品 資 料 介 紹：
- 混合端口密度配置：ENTERASYS SK8009-1224-F8 交換機配備 24 個 10/100/1000Base-T 銅纜端口與 8 個 1000Base-X SFP 光口，同時提供 2 個 10GbE SFP + 上行端口，端口總帶寬達 68Gbps，交換容量高達 136Gbps，可滿足中小企業核心層匯聚與高密度接入雙重需求。
- 全千兆 PoE 供電能力：該交換機支持 IEEE 802.3af/at PoE 標準，24 個銅纜端口均具備 PoE 供電功能，總 PoE 功率預算達 370W，單端口最高輸出 30W，能直接為 IP 攝像頭、Wi-Fi 6 無線 AP、IP 電話等終端供電，減少額外電源布線成本。
- 多層網絡冗余保障：SK8009-1224-F8 內置 IEEE 802.1d STP、802.1w RSTP 與 802.1s MSTP 生成樹協議，支持 802.3ad LACP 鏈路聚合（每組最多 8 個端口，可配置 16 個聚合組），配合 VRRP 虛擬路由冗余協議，實現鏈路與路由雙重冗余，保障業務零中斷。
- 全方位安全防護體系：集成 802.1X 端口認證、MAC 地址綁定（單端口最多綁定 512 個 MAC）與動態 ARP 檢測功能，可有效防范非法接入與 ARP 欺騙攻擊；同時支持 L2-L4 層 ACL 訪問控制，基于端口、IP 地址、端口號等維度精準管控流量，構建立體安全屏障。
- 智能流量管控能力：支持 802.1p 優先級標記與 DSCP 流量分類，每端口配備 8 個優先級隊列，采用 WRR（加權輪詢）與 SP（嚴格優先級）混合調度算法，確保語音、視頻等關鍵業務優先傳輸，避免擁塞導致的服務降級。
- 高效運維管理支持：兼容 Web GUI 圖形化管理與 CLI 命令行管理，支持 SNMPv1/v2c/v3 協議，可接入 Enterasys NetSight 管理平臺實現集中監控與配置；同時具備端口鏡像（支持多對一、一對一模式）與線纜檢測功能，快速定位故障節點，降低運維難度。
- 組播優化處理能力：支持 IGMP v1/v2/v3 snooping 與 MLD snooping 協議，最多可管理 1024 個組播組，配合組播快速離開與組播過濾功能，精準推送視頻會議、IPTV 等組播流，避免帶寬浪費，提升網絡資源利用率。
Extreme Networks SK8009-1224-F8交換機 英文資料：
Mixed port density configuration: The ENTERASYS SK8009-1224-F8 switch is equipped with 24 10/100/1000Base-T copper cable ports and 8 1000Base-X SFP optical ports, while providing 2 10GbE SFP+upstream ports. The total bandwidth of the ports reaches 68Gbps, and the switching capacity is up to 136Gbps, which can meet the dual needs of small and medium-sized enterprise core layer aggregation and high-density access.
Full Gigabit PoE Power Supply Capability: This switch supports the IEEE 802.3af/at PoE standard, with 24 copper ports equipped with PoE power supply. The total PoE power budget is 370W, with a maximum output of 30W per port. It can directly power IP cameras, Wi Fi 6 wireless APs, IP phones, and other terminals, reducing additional power wiring costs.
Multi layer network redundancy guarantee: SK8009-1224-F8 has built-in IEEE 802.1d STP, 802.1w RSTP, and 802.1s MSTP spanning tree protocols, supports 802.3ad LACP link aggregation (up to 8 ports per group, can configure 16 aggregation groups), and works with VRRP virtual routing redundancy protocol to achieve dual redundancy of links and routes, ensuring zero interruption of business.
Comprehensive security protection system: integrating 802.1X port authentication, MAC address binding (up to 512 MACs can be bound to a single port), and dynamic ARP detection functions, which can effectively prevent illegal access and ARP spoofing attacks; Simultaneously supporting L2-L4 layer ACL access control, accurately controlling traffic based on dimensions such as port, IP address, and port number, and building a three-dimensional security barrier.
Intelligent traffic control capability: Supports 802.1p priority tagging and DSCP traffic classification, with 8 priority queues per port, using a mixed scheduling algorithm of WRR (weighted polling) and SP (strict priority) to ensure priority transmission of critical services such as voice and video, avoiding service degradation caused by congestion.
Efficient operation and maintenance management support: compatible with Web GUI graphical management and CLI command line management, supports SNMP v1/v2 c/v3 protocols, can be integrated with Enterasys NetSight management platform for centralized monitoring and configuration; At the same time, it has port mirroring (supporting many to one and one to one modes) and cable detection functions to quickly locate faulty nodes and reduce the difficulty of operation and maintenance.
Multicast optimization processing capability: Supports IGMP v1/v2/v3 snooping and MLD snooping protocols, can manage up to 1024 multicast groups, and with multicast fast departure and multicast filtering functions, accurately pushes multicast streams such as video conferences and IPTV, avoiding bandwidth waste and improving network resource utilization.
Extreme Networks SK8009-1224-F8交換機 產品展示
產品視頻
