Extreme Networks   VSP7400-48Y端口交換機

1.產 品 資 料 介 紹：

Extreme Networks  VSP7400-48Y端口交換機 英文資料：

25G high-density port, suitable for high-speed access: Extreme VSP7400-48Y is equipped with 48 25GE SFP28 optical ports, plus 6 100GE QSFP28 uplink optical ports. The 25G port is connected to high-speed terminals such as servers and storage, and the 100G port is connected to the core network, accurately matching the high-density and high-speed access needs of large data centers and cloud computing nodes.

Ultra high performance, non blocking transmission: switch capacity up to 3.36Tbps, packet forwarding rate up to 2496Mpps, all ports support full duplex line speed forwarding, even if 48 25G ports are running at full load simultaneously, large file transfer and virtual machine migration can be smooth without buffering.

Core layer management capability and intelligent operation and maintenance: As a high-end managed switch, it is equipped with the Extreme VOSS system, supporting web, CLI, SNMP v3, and cloud based Extreme Cloud IQ management. It can remotely configure BGP/OSPF routing, monitor traffic topology, and automatically generate operation and maintenance reports, making complex network management more efficient.

Flexible port splitting to adapt to various devices: The 25GE SFP28 port supports 10G/25G rate adaptation, and the 100GE port can be split into four 25G ports for flexible docking with new and old devices, without the need to ｒｅｐｌａｃｅ additional modules to adapt to different bandwidth requirements.

IPv6 native support, worry free for the future: deeply compatible with IPv4/IPv6 dual stack, supports IPv6 routing protocol, address auto configuration, and transition technology, can seamlessly cope with network address upgrades, avoid device replacement due to protocol iteration, and extend service life.

Multiple redundancy design, zero interruption operation: equipped with dual-mode modular power supply, dual fan group, supporting hot swappable replacement; The core components adopt a redundant architecture, which automatically switches when a single component fails, and cooperates with Link Aggregation (LACP) to ensure the continuous operation of the core layer network.

Comprehensive security protection, more reliable data: built-in MACsec end-to-end encryption, 802.1X authentication, dynamic ACL access control, and can also defend against DDoS attacks, intercept unauthorized access and data eavesdropping, in line with high-end industry security standards such as finance and government.

Modular rack design, easy to expand: adopting a 2RU standard rack height and reserving modular interfaces, management modules or expansion cards can be added according to needs. In the later stage of business growth, there is no need to ｒｅｐｌａｃｅ the entire machine, and hardware upgrades can be directly used to enhance capabilities.

Intelligent energy-saving technology reduces operation and maintenance costs: supports dynamic power regulation of ports, automatically reduces speed and saves energy when idle; The whole machine adopts low-power components, which comply with the EU CEC energy-saving standards. Long term operation can significantly reduce data center electricity expenses.

Original high-end quality, guaranteed service: As the flagship model of Extreme core layer, it has undergone rigorous tests such as high and low temperature, vibration, etc., and has extremely strong stability; Paired with a 5-year original factory warranty and 7 × 24-hour technology, the fault response is rapid and the core network operation and maintenance is more worry free.

Extreme Networks  VSP7400-48Y端口交換機 產品展示

 產品視頻
