BENTLY 3500/22M 138607-01 瞬態數據接口
1.產 品 資 料 介 紹：
- 瞬態數據采集超精準：BENTLY 3500/22M（138607-01）是專業瞬態數據接口，能快速采集旋轉機械的振動、轉速、位移等瞬態數據，比如汽輪機的突發振動信號、電機的轉速波動數據，捕捉速度快且數據精度高，為設備故障分析提供準確依據。
- 適配 3500 監測系統：專為 BENTLY 3500 機械保護系統設計，能無縫對接 3500 系列監測模塊，不用額外調試就能接入現有系統，快速擴展瞬態數據采集功能，特別適合電廠、化工廠等依賴 3500 系統的場景。
- 多信號類型兼容：支持振動、位移、轉速等多種模擬量與數字量信號輸入，能連接加速度傳感器、渦流探頭等不同類型監測設備，不用更換接口就能采集多維度機械數據，適配性強。
- 惡劣環境穩運行：能在 0℃~65℃溫度范圍工作，防塵防潮且抗電磁干擾，工業現場的粉塵、潮濕環境，以及設備運行時的電磁輻射，都不會影響其數據采集穩定性，不易出故障。
- 數據傳輸速度快：具備高速數據傳輸能力，采集到的瞬態數據能快速傳輸?shù)缴衔粰C(jī)或數據分析系統，比如設備突發異常時，能及時將振動峰值數據傳至監控平臺，為緊急處置爭取時間。
- 模塊化安裝省空間：采用 BENTLY 3500 系統標準模塊化設計，能直接安裝在 3500 框架中，與其他監測模塊緊湊布局，不額外占用控制柜空間，適合系統集成化程度高的場景。
- 故障預警易排查：帶狀態指示燈，電源通斷、數據傳輸是否正常、接口是否故障，看燈就能初步判斷；還能通過系統反饋故障代碼，維修人員不用逐個檢測線路，快速定位問題，縮短排查時間。
- 寬壓供電易適配：支持 24V 直流標準工業電源，和現場常用的控制柜電源直接匹配，不用額外定制專用電源，接線簡單，安裝時不用反復調整供電參數，省時省力。
- 數據存儲助分析：可配合系統實現瞬態數據臨時存儲，當設備出現異常時，能保存故障前后的關鍵數據，后續分析故障原因、追溯故障過程時，有完整數據支撐，方便精準診斷。
- 合規性與耐用性雙保障：符合工業設備安全認證標準，采用工業級耐磨、抗腐蝕材質，能承受機械振動與現場沖擊，平均無故障時間長，長期在旋轉機械監測場景使用也省心，減少維護成本。
BENTLY 3500/22M 138607-01 瞬態數據接口 英文資料：
Ultra precise transient data acquisition: BENTLY 3500/22M (138607-01) is a professional transient data interface that can quickly collect transient data such as vibration, speed, displacement, etc. of rotating machinery, such as sudden vibration signals of steam turbines and speed fluctuation data of motors. It captures data quickly and accurately, providing accurate basis for equipment fault analysis.
Compatible with 3500 Monitoring System: Designed specifically for BENTLY 3500 mechanical protection systems, it can seamlessly integrate with 3500 series monitoring modules without additional debugging to quickly expand transient data acquisition capabilities. It is particularly suitable for scenarios such as power plants and chemical plants that rely on the 3500 system.
Multi signal type compatibility: supports various analog and digital signal inputs such as vibration, displacement, and speed, and can connect different types of monitoring devices such as acceleration sensors and eddy current probes. It can collect multi-dimensional mechanical data without changing interfaces and has strong adaptability.
Stable operation in harsh environments: capable of working within a temperature range of 0 ℃~65 ℃, dustproof, moisture-proof, and resistant to electromagnetic interference. The dust, humid environment in industrial sites, as well as electromagnetic radiation during equipment operation, will not affect its data acquisition stability and are not prone to malfunctions.
Fast data transmission speed: With high-speed data transmission capability, the collected transient data can be quickly transmitted to the upper computer or data analysis system. For example, in case of sudden equipment abnormalities, the vibration peak data can be promptly transmitted to the monitoring platform to buy time for emergency response.
Modular installation saves space: Adopting the BENTLY 3500 system standard modular design, it can be directly installed in the 3500 framework, with a compact layout with other monitoring modules, without occupying additional control cabinet space, suitable for scenarios with high system integration.
Fault warning and easy troubleshooting: equipped with status indicator lights, whether the power supply is on or off, whether data transmission is normal, and whether the interface is faulty can be preliminarily judged by looking at the lights; It can also provide feedback on fault codes through the system, so that maintenance personnel do not need to inspect each line one by one, quickly locate the problem, and shorten the troubleshooting time.
Wide voltage power supply easy to adapt: supports 24V DC standard industrial power supply, directly matches with commonly used control cabinet power supply on site, no need to customize special power supply, simple wiring, no need to repeatedly adjust power supply parameters during installation, saving time and effort.
Data storage assistance analysis: It can be used in conjunction with the system to temporarily store transient data. When the device encounters an abnormality, it can save key data before and after the fault. When analyzing the cause of the fault and tracing the fault process, it has complete data support, which facilitates accurate diagnosis.
Dual guarantee of compliance and durability: Compliant with industrial equipment safety certification standards, made of industrial grade wear-resistant and corrosion-resistant materials, capable of withstanding mechanical vibration and on-site impact, with a long average time between failures. Long term use in rotating machinery monitoring scenarios is also worry free, reducing maintenance costs.
BENTLY 3500/22M 138607-01 瞬態數據接口 產品展示
