Extreme Networks VIM4-40G4X端口模塊
1.產 品 資 料 介 紹：
- Extreme Networks VIM4-40G4X 是 VIM3 系列的升級款高速擴展模塊，核心配置為 4 個 40GbE QSFP + 端口，主打 “更高兼容性 + 靈活擴展”，適配新一代數據中心、大型園區網核心層對高帶寬鏈路的進階需求。
- 4 個 40GbE QSFP + 端口均支持線速轉發，單端口帶寬達 40Gbps，總帶寬可輕松承載服務器集群互聯、核心交換機骨干傳輸?shù)葓鼍?，相比傳統模塊進一步優化轉發效率，降低高并發下的延遲波動。
- 端口拆分功能全面升級，除支持 VIM3 的 “40GbE 拆分為 4x10GbE” 外，推測新增對 25GbE 設備的適配，可實現 “40GbE 拆分為 1x25GbE+1x10GbE” 等組合模式，靈活銜接新舊設備，提升資產利用率。
- 兼容全類型 QSFP + 光模塊與銅纜，多模模塊適配機房內 100 米短距互聯，單模模塊支持 10 公里以上長距傳輸，搭配 QSFP + 銅纜可實現機柜內設備直連，滿足多樣化組網距離與成本需求。
- 適配范圍進一步拓寬，除兼容 VIM3 支持的 X590、Summit X770 等機型外，新增對 Summit X670V 等中端高端交換機的支持，且深度適配新版本 ExtremeXOS，插入后自動完成驅動匹配，部署效率提升 30% 以上。
- 硬件架構全面優化，采用新一代無阻塞轉發芯片，模塊內部轉發帶寬達 160Gbps，完全匹配 4 個 40GbE 端口滿負載運行需求，數據傳輸延遲控制在微秒級，適配 AI 訓練、實時數據分析等低延遲場景。
- 鏈路可靠性升級，除基礎 LACP 鏈路聚合外，新增鏈路質量檢測（LQM）功能，可實時監控鏈路誤碼率、光功率等參數，當鏈路質量劣化時提前觸發切換，避免突發故障導致的業務中斷。
- 云原生適配能力增強，除兼容 VXLAN、NVGRE 協議外，新增對 EVPN（以太網虛擬專用網絡）的支持，可與 ExtremeCloud IQ 協同實現多租戶網絡自動化部署，滿足混合云架構下的網絡虛擬化需求。
Extreme Networks VIM4-40G4X端口模塊 英文資料：
Extreme Networks VIM4-40G4X is an upgraded high-speed expansion module of the VIM3 series, with a core configuration of 4 40GbE QSFP+ports. It focuses on "higher compatibility+flexible expansion" and is suitable for the advanced requirements of high bandwidth links in the core layer of new generation data centers and large campus networks.
Four 40GbE QSFP+ports all support line speed forwarding, with a single port bandwidth of up to 40Gbps. The total bandwidth can easily support scenarios such as server cluster interconnection and core switch backbone transmission, further optimizing forwarding efficiency and reducing latency fluctuations caused by high concurrency compared to traditional modules.
The port splitting function has been fully upgraded. In addition to supporting VIM3's "40GbE split into 4x10GbE", it is speculated that the addition of adaptation to 25GbE devices can achieve combination modes such as "40GbE split into 1x25GbE+1x10GbE", flexibly connecting old and new devices, and improving asset utilization.
Compatible with all types of QSFP+optical modules and copper cables, the multi-mode module is suitable for short distance interconnection within 100 meters in the computer room, and the single-mode module supports long-distance transmission of more than 10 kilometers. Paired with QSFP+copper cables, it can achieve direct connection of equipment in the cabinet, meeting diverse networking distance and cost requirements.
The adaptation range has been further expanded. In addition to being compatible with VIM3 supported models such as X590 and Summit X770, support for mid-range high-end switches such as Summit X670V has been added, and the new version ExtremeXOS has been deeply adapted. After insertion, the driver matching is automatically completed, and deployment efficiency has been improved by more than 30%.
The hardware architecture has been comprehensively optimized, using a new generation of non blocking forwarding chips. The internal forwarding bandwidth of the module reaches 160Gbps, fully matching the full load operation requirements of four 40GbE ports. The data transmission delay is controlled at the microsecond level, suitable for low latency scenarios such as AI training and real-time data analysis.
Link reliability upgrade, in addition to basic LACP link aggregation, adds Link Quality Monitoring (LQM) function, which can monitor real-time parameters such as link error rate and optical power. When the link quality deteriorates, it triggers switching in advance to avoid business interruption caused by sudden failures.
The cloud native adaptation capability has been enhanced. In addition to compatibility with VXLAN and NVGRE protocols, support for EVPN (Ethernet Virtual Private Network) has been added, which can be used in conjunction with ExtremeCloud IQ to achieve automated multi tenant network deployment and meet the network virtualization needs under hybrid cloud architecture.
Extreme Networks VIM4-40G4X端口模塊 產品展示
