Extreme Networks 41515 700102-00-06端口模塊
1.產 品 資 料 介 紹：
- 設備適配：匹配 Extreme Networks 高端模塊化交換機（如 Summit X 系列、ExtremeSwitching 系列），作為核心端口擴展模塊，適配數據中心、企業骨干網的高密度接入場景，可直接嵌入交換機空槽位實現端口擴容。
- 網絡兼容：聚焦以太網高速傳輸場景，兼容 IEEE 802.3 系列標準，支持千兆 / 萬兆速率自適應，適配 IPv4/IPv6 雙棧網絡環境，可與現有網絡架構無縫銜接，無需調整核心路由配置。
- 核心功能：提供多端口數據轉發與鏈路聚合能力，承擔服務器集群、存儲區域網絡（SAN）的高速數據交互，配合交換機主控系統實現流量負載均衡與鏈路冗余保護，保障網絡傳輸連續性。
- 端口性能：采用 SFP/SFP + 光模塊接口設計，單端口傳輸速率可達 1Gbps/10Gbps，支持全雙工模式，端口總帶寬≥40Gbps，滿足高密度數據并發傳輸需求。
- 轉發性能：包轉發率≥14.88Mpps（千兆端口）/148.8Mpps（萬兆端口），傳輸延遲≤5μs，支持存儲 - 轉發交換方式，可精準過濾無效幀，避免網絡帶寬浪費。
- 協議兼容：支持 IEEE 802.3ad 鏈路聚合（LACP）、802.1Q VLAN 劃分、802.1p 優先級隊列，兼容 Spanning Tree Protocol（STP）及快速生成樹協議（RSTP），保障網絡架構穩定性。
- 防護設計：外殼采用工業級金屬材質，具備電磁屏蔽（EMC）設計，通過 EN 55032 Class B 電磁兼容測試，可抵御數據中心復雜電磁環境干擾；接口觸點采用鍍金工藝，降低信號衰減與氧化損耗。
- 安裝適配：采用標準模塊化設計（尺寸適配交換機槽位規范），支持熱插拔功能，安裝時無需關閉交換機電源，單模塊更換時間≤2 分鐘，適配數據中心不停機維護需求。
- 操作便利：配備端口狀態指示燈（Link/Act、Speed），可直觀判斷鏈路連接與傳輸速率狀態；支持通過 Extreme Management Center（XMC）平臺遠程監控模塊運行參數，實現固件在線升級。
Extreme Networks 41515 700102-00-06端口模塊 英文資料：
1. Adaptation scenarios and functions (41515 700102-00-06)
Device adaptation: Match with Extreme Networks high-end modular switches (such as Summit X series, ExtremeSwitching series) as core port expansion modules, suitable for high-density access scenarios in data centers and enterprise backbone networks, and can be directly embedded in switch slots to achieve port expansion.
Network compatibility: Focusing on high-speed Ethernet transmission scenarios, compatible with the IEEE 802.3 series standards, supporting gigabit/ten gigabit rate adaptation, compatible with IPv4/IPv6 dual stack network environments, and can seamlessly integrate with existing network architectures without the need to adjust core routing configurations.
Core function: Provide multi port data forwarding and link aggregation capabilities, undertake high-speed data exchange between server clusters and storage area networks (SANs), cooperate with switch control systems to achieve traffic load balancing and link redundancy protection, and ensure network transmission continuity.
2. Accuracy and Performance (41515 700102-00-06)
Port performance: Designed with SFP/SFP+optical module interface, the single port transmission rate can reach 1Gbps/10Gbps, supporting full duplex mode, and the total port bandwidth is ≥ 40Gbps, meeting the requirements of high-density data concurrent transmission.
Forwarding performance: Packet forwarding rate ≥ 14.88Mpps (gigabit port)/148.8Mpps (ten gigabit port), transmission delay ≤ 5 μ s, supports store forward switching mode, can accurately filter invalid frames, and avoid network bandwidth waste.
Protocol compatibility: Supports IEEE 802.3ad Link Aggregation (LACP), 802.1Q VLAN partitioning, 802.1p priority queue, compatible with Spanning Tree Protocol (STP) and Fast Spanning Tree Protocol (RSTP), ensuring network architecture stability.
3. Structure and Protection (41515 700102-00-06)
Protection design: The shell is made of industrial grade metal material and has electromagnetic shielding (EMC) design. It has passed EN 55032 Class B electromagnetic compatibility testing and can resist complex electromagnetic environment interference in data centers; The interface contacts adopt gold plating technology to reduce signal attenuation and oxidation loss.
Installation adaptation: Adopting standard modular design (size adaptation switch slot specification), supporting hot plugging function, no need to turn off the switch power during installation, single module replacement time ≤ 2 minutes, suitable for non-stop maintenance needs of data centers.
Easy to operate: equipped with port status indicator lights (Link/ACT, Speed), which can intuitively determine the link connection and transmission rate status; Support remote monitoring of module operation parameters through the Extreme Management Center (XMC) platform to achieve online firmware upgrades.
Extreme Networks 41515 700102-00-06端口模塊 產品展示
