AMAT Applied Materials 0100-90311接口模塊
1.產 品 資 料 介 紹：
- 設備適配：匹配 AMAT 半導體工藝設備（如蝕刻、沉積機臺），作為主控單元與外設的信號樞紐，適配傳感器、執行器及控制模塊等設備連接需求。
- 工藝兼容：聚焦半導體潔凈車間環境，適配真空抽排、氣體輸送等工序的信號傳輸，支持與 AMAT SmartFactory 良率管理系統聯動。
- 核心功能：實現數字 / 模擬信號的雙向轉換與傳輸，承擔控制指令下發、設備狀態數據回傳功能，保障多組件協同運行。
- 傳輸性能：支持 RS-232/RS-485 串行接口與以太網口，RS-485 通信距離可達 1000 米，以太網速率 10/100Mbps 自適應，波特率 300-115200bps 可調。
- 協議兼容：支持 Modbus RTU 主從應答協議，兼容 TCP、UDP、HTTP 等網絡協議，可接入 AMAT 設備 PLC 系統實現遠程監控。
- 運行穩定：內置信號隔離電路（隔離電壓≥1000VDC），抗干擾能力強，平均無故障時間（MTBF）超 5000 小時，適配工業級連續運行需求。
- 防護設計：外殼采用工業級阻燃材質，具備防靜電（ESD）、防電磁干擾（EMI）設計，適應半導體車間復雜電磁環境。
- 安裝適配：緊湊型結構（尺寸約 90×50×18mm），支持 DIN35mm 導軌式安裝，接線端子帶防呆設計，避免誤接損壞模塊。
- 維護便利：配備狀態指示燈（電源、通信、故障），支持通過 Windows 配置軟件調試參數，提供 API 函數庫便于二次開發。
- 認證：通過 UL 工業設備安全認證、CE 電磁兼容認證，符合 RoHS 2.0 環保標準，適配全球晶圓廠合規要求。
- 環境耐受：工作溫度 - 20-60℃（相對濕度 5%-95%，無冷凝），存儲溫度 - 40-85℃，支持 24VDC 寬壓輸入（±10%）及過流保護。
- 安全機制：內置信號故障檢測功能，異常時自動切斷輸出并發送報警信號，防止錯誤信號導致工藝中斷。
AMAT Applied Materials 0100-90311接口模塊 英文資料：
1. Adaptation scenarios and functions (0100-90311)
Equipment adaptation: Match AMAT semiconductor process equipment (such as etching and deposition machines) as a signal hub between the main control unit and peripherals, and adapt to the connection requirements of sensors, actuators, and control modules.
Process compatibility: Focusing on the semiconductor clean room environment, adapting to signal transmission for vacuum pumping, gas transportation and other processes, supporting linkage with AMAT SmartFactory yield management system.
Core function: Implement bidirectional conversion and transmission of digital/analog signals, undertake control command issuance and equipment status data feedback functions, and ensure the coordinated operation of multiple components.
2. Accuracy and Performance (0100-90311)
Transmission performance: Supports RS-232/RS-485 serial interface and Ethernet port, with a communication distance of up to 1000 meters for RS-485, adaptive Ethernet speed of 10/100Mbps, and adjustable baud rate of 300-115200bps.
Protocol compatibility: Supports Modbus RTU master-slave response protocol, compatible with TCP, UDP, HTTP and other network protocols, and can be connected to AMAT device PLC system for remote monitoring.
Stable operation: Built in signal isolation circuit (isolation voltage ≥ 1000VDC), strong anti-interference ability, mean time between failures (MTBF) exceeding 5000 hours, suitable for industrial grade continuous operation requirements.
3. Structure and Protection (0100-90311)
Protection design: The shell is made of industrial grade flame-retardant material, with anti-static (ESD) and electromagnetic interference (EMI) design, suitable for the complex electromagnetic environment of semiconductor workshops.
Installation adaptation: Compact structure (size approximately 90 × 50 × 18mm), supporting DIN35mm rail installation, with foolproof design of wiring terminals to avoid module damage caused by misconnection.
Easy maintenance: equipped with status indicator lights (power, communication, fault), supports debugging parameters through Windows configuration software, and provides API function libraries for secondary development.
4. Compliance and Assurance (0100-90311)
Certification: Passed UL industrial equipment safety certification, CE electromagnetic compatibility certification, compliant with RoHS 2.0 environmental standards, and adaptable to global wafer fab compliance requirements.
Environmental tolerance: Operating temperature -20-60 ℃ (relative humidity 5% -95%, no condensation), storage temperature -40-85 ℃, supporting 24VDC wide voltage input (± 10%) and overcurrent protection.
Security mechanism: Built in signal fault detection function, automatically cuts off output and sends alarm signals when abnormal, preventing process interruption caused by incorrect signals.
AMAT Applied Materials 0100-90311接口模塊 產品展示
產品視頻
