AMAT Applied Materials 0190-16537電源模塊
1.產 品 資 料 介 紹：
- 功率規格：800W 高功率輸出（直流模式），滿足半導體蝕刻設備大負載供電需求
- 適配設備：專為 AMAT 300mm XP 系列蝕刻機設計，可精準匹配設備功率接口與控制邏輯
- 輸入兼容性：參考同類 AMAT 電源特性，預計支持寬范圍交流輸入（如 85-264VAC），適配不同地區電網
- 穩壓精度：采用開關電源技術，輸出電壓紋波低（參考同類模塊≤1%），保障蝕刻工藝電流穩定
- 散熱設計：可能內置高效散熱片 + 智能溫控風扇，快速導出 800W 負載產生的熱量，避免過熱降額
- 響應速度：針對蝕刻設備脈沖負載，具備毫秒級動態響應能力，減少電壓波動對晶圓加工的影響
- 多重保護：內置過載、短路、過壓保護功能，出現異常時自動切斷輸出，保護模塊及下游設備
- 隔離特性：采用 Class Ⅱ 級電氣隔離設計，輸入與輸出回路物理隔離，降低漏電風險
- 故障診斷：配備狀態指示燈，可快速識別電源通斷、過載等故障，簡化檢修流程
- 環境耐受：工作溫度范圍預計達 0-75℃，適配半導體潔凈車間溫濕度環境
- 認證標準：通過 UL（美國）、CE（歐盟）安全認證，符合 RoHS 環保要求，適配國際市場
- 結構耐用：金屬外殼封裝，抗振動性能強，適配半導體車間設備運行時的機械振動環境
AMAT Applied Materials 0190-16537電源模塊 英文資料：
1. Power and adaptability (0190-16537 power module)
Power specification: 800W high-power output (DC mode), meeting the high load power supply requirements of semiconductor etching equipment
Adaptation equipment: specially designed for AMAT 300mm XP series etching machines, capable of accurately matching device power interfaces and control logic
Input compatibility: Referring to the characteristics of similar AMAT power supplies, it is expected to support a wide range of AC inputs (such as 85-264VAC) and adapt to different regional power grids
2. Performance and stability (0190-16537 power module)
Voltage stabilization accuracy: Using switching power supply technology, the output voltage ripple is low (reference to similar modules ≤ 1%), ensuring stable etching process current
Heat dissipation design: It may have built-in high-efficiency heat sinks and intelligent temperature controlled fans to quickly dissipate the heat generated by an 800W load, avoiding overheating and derating
Response speed: With millisecond level dynamic response capability for pulse loads in etching equipment, it reduces the impact of voltage fluctuations on wafer processing
3. Safety and Protection (0190-16537 Power Module)
Multiple protection: Built in overload, short circuit, and overvoltage protection functions, automatically cutting off output in case of abnormalities, protecting modules and downstream equipment
Isolation characteristics: Adopting Class II electrical isolation design, the input and output circuits are physically isolated to reduce the risk of leakage
Fault diagnosis: Equipped with status indicator lights, it can quickly identify faults such as power on/off and overload, simplifying the maintenance process
4. Compliance and Durability (0190-16537 Power Module)
Environmental tolerance: The expected working temperature range is 0-75 ℃, suitable for the temperature and humidity environment of semiconductor clean rooms
Certification standards: UL (USA) and CE (EU) safety certifications have been passed, meeting RoHS environmental requirements and adapting to the international market
Durable structure: metal shell packaging, strong anti vibration performance, suitable for the mechanical vibration environment during the operation of semiconductor workshop equipment
AMAT Applied Materials 0190-16537電源模塊 產品展示
產品視頻
