Extreme Networks X460-G2-48P-10機架托管交換機
1.產 品 資 料 介 紹：
- PoE + 接入端口：配備 48 個 10/100/1000 BASE-T 自適應電口，全部支持 IEEE 802.3af/at PoE + 標準，單端口最大輸出 30W 功率，可同時為 IP 電話、雙頻無線 AP、高清球機等 48 臺終端供電，無需額外部署電源模塊，適配企業總部樓層、大型園區等高密度終端場景。
- 10G 上行擴展端口：含 4 個 SFP+ 10G 光口（非復用設計），支持 10GBASE-SR/LR 等光模塊，可直連核心交換機（如 Extreme X670 系列）或服務器，實現 10Gbps 高速上行，解決傳統千兆上行的帶寬瓶頸，滿足視頻會議、大數據傳輸?shù)葞捗芗蜆I(yè)務需求。
- 靈活擴展接口：預留 2 個模塊化插槽（如 XGM2 模塊插槽），可擴展更多 10G 光口或萬兆電口，適配業務增長后的端口擴容需求，避免設備重復采購。
- PoE 功率保障：整機 PoE 功率預算高達 740W，可滿負荷為 48 個 PoE + 設備供電（48×30W=1440W，實際支持 740W，滿足多數場景下高功耗終端混合接入），即使接入 48 臺雙頻 AP（單臺約 15-25W），也無需擔心功率不足，無需額外配置 PoE 擴展模塊。
- 核心性能參數：交換容量達 256Gbps，轉發速率 192Mpps，64 字節數據包時延低于 3μs，兼容 9KB 巨幀；48 個千兆電口與 4 個 10G 光口均支持線速轉發，端口總帶寬之和的兩倍（48×2Gbps + 4×20Gbps = 176Gbps）遠低于交換容量，確保無阻塞傳輸，避免多終端并發導致的網絡卡頓。
- 智能流量管控：提供 16 個出口 QoS 隊列，支持基于 802.1p、DSCP、IP 優先級的多層級流量分類，可為語音（DSCP EF）、視頻（DSCP CS4）等關鍵業務分配專屬帶寬，配合 WRED 擁塞避免機制，保障高優先級業務的流暢性。
Extreme Networks X460-G2-48P-10機架托管交換機 英文資料：
1. High density PoE+and 10G uplink configuration: suitable for medium to large access scenarios
The Extreme Networks X460-G2-48P-10, as a mid to high end access layer/aggregation layer model, features a port design centered around "high-density power supply+high-speed uplink" to meet the needs of large-scale terminal access
PoE+access ports: equipped with 48 10/100/1000 BASE-T adaptive electrical ports, all supporting IEEE 802.3af/at PoE+standards, with a maximum output power of 30W per port, capable of supplying power to 48 terminals such as IP phones, dual band wireless APs, high-definition dome cameras, etc. without the need for additional power modules, suitable for high-density terminal scenarios such as enterprise headquarters floors and large parks.
10G uplink expansion port: includes 4 SFP+10G optical ports (non multiplexed design), supports 10GBASE-SR/LR and other optical modules, can directly connect to core switches (such as Extreme X670 series) or servers, achieve 10Gbps high-speed uplink, solve the bandwidth bottleneck of traditional gigabit uplink, and meet bandwidth intensive business needs such as video conferences and big data transmission.
Flexible expansion interface: Reserve 2 modular slots (such as XGM2 module slots), which can expand more 10G optical ports or 10G electrical ports, adapt to the port expansion needs after business growth, and avoid duplicate equipment procurement.
2. High power PoE and high-performance forwarding: balancing power supply and transmission efficiency
Extreme Networks X460-G2-48P-10 balances high-density PoE power supply and data forwarding performance, supporting medium to large network loads:
PoE power guarantee: The overall PoE power budget is as high as 740W, which can supply power to 48 PoE+devices at full load (48 × 30W=1440W, actually supporting 740W, meeting the mixed access of high-power terminals in most scenarios). Even if 48 dual band APs are connected (each about 15-25W), there is no need to worry about insufficient power or additional PoE expansion modules.
Core performance parameters: exchange capacity up to 256Gbps, forwarding rate 192Mpps, 64 byte packet latency less than 3 μ s, compatible with 9KB jumbo frames; 48 gigabit electrical ports and 4 10G optical ports both support line speed forwarding, and the total bandwidth of the ports is twice the sum (48 × 2Gbps+4 × 20Gbps=176Gbps), which is much lower than the switching capacity, ensuring non blocking transmission and avoiding network lag caused by multi terminal concurrency.
Extreme Networks X460-G2-48P-10機架托管交換機 產品展示
