AMAT Applied Materials 0100-09099互連組件
1.產 品 資 料 介 紹：
- 作為腔體接口板，集成多類型接口適配半導體設備反應腔組件，支持模擬信號（4-20mA）、數字 I/O 信號及電源信號的集中轉接，兼容熱電偶、壓力傳感器等外設連接。
- 采用 PCB 板載式端子與針腳設計，接口間距符合工業標準，可直接對接 0100-09008 氣動控制板、0120-00794 過程傳感器主板等 AMAT 設備模塊，無需額外轉接件。
- 具備信號整形與中繼功能，可優化長距離傳輸后的信號質量，減少衰減，支持 Modbus 協議信號中轉，助力反應腔數據與 0190-24007 單板計算機的實時交互。
- 承擔腔體與設備主控系統的 “信號橋梁” 角色，實現工藝參數采集、控制指令下發的雙向傳輸，適配蝕刻、沉積等工藝的腔體閉環控制需求。
- 工作溫度覆蓋 - 20~+70℃，濕度耐受 5%-95%（無凝露），表面經防靜電噴涂處理，符合 Class 100 潔凈室粉塵控制要求，適配反應腔周邊嚴苛環境。
- 采用 PCB 板分層屏蔽設計，抗電磁干擾符合 EN 55022 Class B 標準，避免射頻設備干擾導致的信號失真，防護等級達 IP20。
- 核心接口部件選用工業級材質，經 10 萬次插拔與信號傳輸測試，接觸電阻≤50mΩ，支持 7×24 小時連續運行，MTBF≥8 萬小時。
- 符合 UL/CE/RoHS 認證，適配半導體設備高稼動率需求，原廠提供 1-3 年質保，備件可快速替換以縮短停機時間。
AMAT Applied Materials 0100-09099互連組件 英文資料：
1. Interface adaptation performance (AMAT 0100-09099)
As a cavity interface board, it integrates multiple types of interfaces to adapt to semiconductor device reaction cavity components, supports centralized conversion of analog signals (4-20mA), digital I/O signals, and power signals, and is compatible with external connections such as thermocouples and pressure sensors.
Adopting PCB board mounted terminal and pin design, the interface spacing meets industrial standards, and can directly interface with AMAT equipment modules such as 0100-09008 pneumatic control board and 0120-00794 process sensor motherboard without the need for additional adapters.
2. Signal Transmission and Linkage (AMAT 0100-09099)
Equipped with signal shaping and relay functions, it can optimize the signal quality after long-distance transmission, reduce attenuation, support Modbus protocol signal relay, and assist in real-time interaction between reaction chamber data and 0190-24007 single board computer.
Undertake the role of a "signal bridge" between the cavity and the equipment control system, achieve bidirectional transmission of process parameter acquisition and control command issuance, and adapt to the closed-loop control requirements of cavity processes such as etching and deposition.
3. Environment and Protection (AMAT 0100-09099)
The working temperature covers -20~+70 ℃, with a humidity tolerance of 5% -95% (no condensation). The surface has been treated with anti-static spraying, which meets the dust control requirements of Class 100 cleanroom and is suitable for harsh environments around the reaction chamber.
Adopting a PCB board layered shielding design, the anti electromagnetic interference meets the EN 55022 Class B standard, avoiding signal distortion caused by RF equipment interference, and the protection level reaches IP20.
4. Reliability (AMAT 0100-09099)
The core interface components are made of industrial grade materials and have undergone 100000 cycles of plugging and signal transmission testing. The contact resistance is ≤ 50m Ω, and it supports 7 × 24-hour continuous operation with an MTBF of ≥ 80000 hours.
Compliant with UL/CE/RoHS certification, suitable for high utilization requirements of semiconductor equipment, original factory provides 1-3 year warranty, and spare parts can be quickly replaced to shorten downtime.
