AMAT Applied Materials 0100-02420隔離 PCB 板

1.產 品 資 料 介 紹：

AMAT Applied Materials 0100-02420隔離 PCB 板 英文資料：

1、 Product Overview

The AMAT 0100-02420 isolation PCB board is the electrical isolation core component of semiconductor equipment, such as the AMAT Centura series etching machine and Endura series PVD equipment. It mainly realizes signal isolation transmission and power isolation supply between high and low voltage circuits of the equipment, prevents high voltage interference from entering the low voltage control circuit, and protects sensitive control chips and operators. It adopts an integrated design of optocoupler and isolated power supply, which is suitable for multi circuit signal interaction scenarios of semiconductor equipment. It can directly ｒｅｐｌａｃｅ the original PCB board of the same model without adjusting the equipment wiring and interface logic.

2、 Key parameters

Applicable system: Priority adaptation to AMAT Centura/Endura series semiconductor equipment, compatible with signal isolation circuits of similar AMAT equipment

Isolation function: Supports 8-channel signal isolation (4-channel analog 4-20mA/0-10V, 4-channel digital 24V DC), 2-channel power isolation (input DC 24V, output DC 24V/5V)

Isolation voltage: Electrical isolation voltage ≥ 2500V AC (no breakdown for 1 minute), insulation resistance ≥ 1000M Ω (tested at 500V DC)

Signal performance: Analog isolation error ≤ 0.5% FS, digital response time ≤ 10 μ s, supports bidirectional signal transmission

Physical specifications: PCB board dimensions are 100mm in length and 80mm in width. The mounting holes are compatible with the original equipment bracket (M2.5 screws), and the onboard connector model is the same as the original factory

Environmental adaptation: Working temperature -10 ℃ -60 ℃, relative humidity ≤ 90% RH (no condensation), flame retardant grade UL94 V-0, anti electromagnetic interference in accordance with EN 61000-6-2 standard

Power requirement: Isolated power input DC 24V ± 10%, power consumption ≤ 15W (full load operation)

3、 Core advantages

High isolation reliability: The dual isolation design of optocoupler and isolation power supply ensures that the isolation voltage and insulation performance meet the high-voltage protection requirements of semiconductor equipment, avoiding signal distortion caused by interference

Seamless compatibility with the original factory: PCB board size, connector definition, signal pins are completely matched with the original factory, and there is no need to re debug isolation parameters after replacement. Installation time is ≤ 30 minutes

Strong durability: using FR-4 fiberglass substrate (temperature resistance ≥ 130 ℃), industrial grade optocoupler and isolation chip, solder joint anti-corrosion treatment, average time between failures (MTBF) ≥ 60000 hours

AMAT Applied Materials 0100-02420隔離 PCB 板 產品展示

 產品視頻
