AMAT Applied Materials 0100-AE018系統主板

1.產 品 資 料 介 紹：

AMAT Applied Materials 0100-AE018系統主板  英文資料：

1、 Product Overview

The AMAT 0100-AE018 system motherboard is the main control center of semiconductor wafer processing equipment, such as the AMAT Endura series PVD coating machine and Centura series etching machine. It is mainly responsible for signal aggregation, instruction distribution, and collaborative scheduling of various functional modules (driver modules, sensors, process control units) of the equipment. At the same time, it realizes data exchange with the upper computer and factory MES system, and is the core carrier of the full process automation operation of the equipment. The motherboard adopts a highly integrated circuit design and anti-interference layout, which can directly ｒｅｐｌａｃｅ the original motherboard of the same model without the need to reconstruct the device control logic, and quickly restore the main control function of the device.

2、 Key parameters

Applicable system: Priority adaptation to AMAT Endura/Century series semiconductor equipment, compatible with the main control system of similar AMAT wafer processing equipment

Core configuration: Industrial grade quad core processor (with a clock speed of 1.5GHz), onboard 2GB DDR4 memory, 16GB eMMC storage (for storing system firmware and process parameters)

Interface resources: 4 EtherCAT interfaces (real-time control module, cycle ≤ 1ms), 2 Gigabit Ethernet interfaces (MES system/upper computer communication), 8 RS485 interfaces (connecting sensors/actuators), 16 digital I/O (24V DC, used for status monitoring), 4 PCIe slots (expansion function module)

Control function: Supports multi module collaborative scheduling (motion control, parallel processing of process parameter adjustment), fault diagnosis and log storage (can store 1000 fault records), process program import/export (supports USB/Ethernet transmission)

Power requirement: DC 24V ± 10% dual redundant input, power consumption ≤ 30W (full load operation), with overvoltage (30V), undervoltage (18V), and overcurrent (2A) protection

Physical dimensions: 300mm in length and 220mm in width (standard ATX version), with installation holes suitable for the original equipment main control cabinet, fixed with M3 screws (torque 0.6-0.8N · m)

Environmental adaptation: Working temperature of 0 ℃ -60 ℃, relative humidity ≤ 85% RH (no condensation), anti electromagnetic interference in accordance with EN 61000-6-4 standard, PCB board flame retardant grade UL94 V-0

3、 Core advantages

High integration control capability: quad core processor+multi interface integration, capable of scheduling 8+functional modules simultaneously, instruction response delay ≤ 500 μ s, meeting the requirements of synchronous operation of multiple processes in equipment

Original factory deep compatibility: The interface definition, firmware protocol, and module communication logic are completely identical to those of the original factory. After replacement, there is no need to re burn the system firmware, only the original process parameters need to be loaded to resume operation. The downtime for replacement is ≤ 2 hours
