AMAT Applied Materials  DNP-CPCI-2掃描儀模塊

1.產 品 資 料 介 紹：

AMAT Applied Materials DNP-CPCI-2掃描儀模塊 英文資料：

1、 Product core positioning

AMAT DNP-CPCI-2 is a high-precision scanner module with CPCI bus architecture specially designed by Applied Materials for high-end semiconductor process inspection. It is the core imaging component of the wafer defect detection and pattern verification system. Its core function is to convert the microscopic patterns and defect features on the wafer surface into digital image data through high-precision optical scanning and electronic signal conversion. Combined with algorithms, it realizes size measurement, defect recognition, and process consistency verification, and is a key detection equipment to ensure semiconductor manufacturing yield.

Unlike general document scanners, this module adopts a semiconductor grade optical system and CPCI industrial bus design, with sub micron imaging accuracy and high-speed data transmission capability. It can adapt to harsh environments in clean workshops and meet the detection needs of advanced processes up to 14nm.

2、 Key technical parameters (derived from industry standards and similar products)

Based on the technical specifications of AMAT testing equipment, CPCI bus standards, and general requirements for semiconductor scanning equipment, the core specifications of this model are speculated as follows:

Parameter category

Specification Description

Optical scanning core

Adopting a high-sensitivity CCD sensor with an optical resolution of ≥ 2000dpi; Equipped with LED cold light source, spectral range of 400-700nm, no thermal radiation effect

Scanning performance characteristics

Scanning speed ≥ 50mm/s (at 1000dpi resolution); Defect detection accuracy ≤ 0.1 μ m, supporting black and white, grayscale (16 bit), and color imaging modes

Bus and Data Transmission

Adopting CPCI 2.2 standard bus interface, data transmission rate ≥ 133MB/s; Support DMA direct data transfer to reduce CPU load

Physical and Environmental Specifications

Dimensions comply with 3U CPCI standard (160 × 100 × 32mm), weight<500g; operating temperature 0-50 ℃, humidity<85%, no condensation, cleanliness Class 10 requirements

Protection and Certification

Surface anti-static coating, interface with dust-proof sealing design; Compliant with UL 61010-1 safety standards and CE electromagnetic compatibility certification

3、 Application scenarios and adaptation systems

1. Core application areas

As the "visual core" of semiconductor inspection, this scanner module mainly serves the critical inspection process:

Wafer pattern verification: adapted to measure the line width (CD) of the wafer after photolithography and detect pattern alignment, verifying the accuracy of the photolithography process through scanning imaging

Defect detection and classification: used for surface inspection of wafers after etching and deposition processes, identifying abnormal features such as scratches, particles, and film defects

Mask quality inspection: Scanning and imaging of micro defects on the surface of photolithography masks to ensure the integrity and accuracy of mask patterns

 AMAT Applied Materials DNP-CPCI-2掃描儀模塊 產品展示

 產品視頻
