AMAT Applied Materials 0190-91072印刷電路板
1.產 品 資 料 介 紹：
- 射頻系統控制：適配等離子體刻蝕 / 沉積設備的射頻功率調節模塊，實現反射功率信號采集與匹配器驅動指令輸出
- 真空工藝調控：用于反應腔壓力、流量的閉環控制電路，連接壓力傳感器與執行器（如氣動閥門）
- 設備狀態監測：承載溫度、電流等關鍵參數的檢測電路，為設備故障預警系統提供信號輸入
AMAT Applied Materials 0190-91072印刷電路板 英文資料：
1、 Product core positioning
AMAT 0190-91072 is a high-precision control printed circuit board designed by Applied Materials for high-end semiconductor process equipment. It belongs to the "signal center" of the equipment's core electronic control system. Its core function is to support and interconnect key electronic components, achieve real-time acquisition of equipment operating parameters, signal conversion, and instruction transmission. Especially in high-precision modules such as RF systems and vacuum control, it plays a role in signal scheduling and is the core hardware carrier to ensure equipment process stability and operational response speed.
Compared with general industrial PCBs, this model uses semiconductor grade special substrate materials and high-density wiring design, which can withstand high-frequency electromagnetic interference and temperature fluctuations during equipment operation, and is suitable for harsh working environments in clean workshops.
2、 Key technical parameters (derived from industry standards and similar products)
Based on the technical specifications of AMAT electronic control components and the general requirements of semiconductor equipment PCB, the core specifications of this model are speculated as follows:
Parameter category
Specification Description
Substrate and Material
Using bismaleimide triazine (BMI) resin substrate, glass transition temperature (Tg) ≥ 177 ℃, dielectric constant 3.2-3.6 (at 1GHz)
Circuit and wiring characteristics
6-8 layer wiring structure, line width/spacing ≥ 3mil/3mil, impedance control ± 10%, supporting a maximum signal transmission rate of 100Mbps
Components and Connections
Integrated high-precision operational amplifier, isolated ADC/DAC chip, using surface mount technology (SMT); Interface with gold-plated pin connector
Physical and Environmental Specifications
Size approximately 220 × 180 × 2.4mm, weight<200g; working temperature -10-60 ℃, humidity<90%, no condensation, anti vibration level IEC 60068-2-6
Protection and Certification
Surface covered with solder mask green oil and equipped with moisture-proof coating; Compliant with UL 94 V-0 flame retardant standard and Class 100 cleanliness requirements for semiconductor equipment
3、 Application scenarios and adaptation systems
1. Core application areas
As a key component of the electronic control system, this PCB mainly serves the high-precision control process in semiconductor manufacturing
RF system control: RF power regulation module adapted to plasma etching/deposition equipment, realizing the acquisition of reflected power signals and the output of matching device driving instructions
Vacuum process control: a closed-loop control circuit used for reaction chamber pressure and flow, connecting pressure sensors and actuators (such as pneumatic valves)
Equipment status monitoring: a detection circuit that carries key parameters such as temperature and current, providing signal input for the equipment fault warning system
AMAT Applied Materials 0190-91072印刷電路板 產品展示
產品視頻
