Extreme Networks BDXA-40G24X交換機模塊
1.產 品 資 料 介 紹：
- 核心適配：Extreme Networks BDXA-40G24X 是高密度 40G 光口擴展模塊，適配 ExtremeSwitching 系列高端機箱式交換機，專為高端口密度場景設計，滿足數據中心大規模設備互聯的帶寬擴展需求。
- 接口規格：配備 24 個 40GBASE-X QSFP + 光口，單端口速率達 40Gbps，可搭配單模（傳輸距離≤40 公里）、多模（傳輸距離≤100 米）QSFP + 光模塊，靈活適配不同距離的設備互聯場景。
- 性能支撐：采用全非阻塞線速架構，整機吞吐量無瓶頸，單端口轉發速率穩定 40Gbps，可高效承載服務器集群互聯、大流量數據備份等高頻高帶寬業務，保障傳輸流暢性。
- 管理兼容：無縫對接 Extreme Management Center（XMC）平臺，支持批量配置 VLAN 與 QoS 優先級，兼容 SNMPv3 協議，可實時監控端口流量、模塊狀態，實現集中化運維管控。
- 安全防護：具備硬件級 ACL 訪問控制，可基于 IP、MAC 地址限制數據訪問；支持端口安全綁定，防范非法設備接入，同時抵御 ARP 欺騙、DHCP 泛洪等常見網絡攻擊。
- 可靠部署：支持熱插拔設計，故障時可在線更換不中斷業務；適配交換機冗余電源架構，配合鏈路故障快速檢測機制，提升網絡運行連續性與可靠性。
- 運維便捷性：自帶端口與全局狀態指示燈，直觀顯示連接、速率及運行狀態；支持遠程故障診斷，可通過管理平臺查看錯誤幀、光功率等參數，便于快速排查問題。
- 環境適應性：采用低功耗 QSFP + 光口設計，能耗優于同類型高密度模塊，且能在數據中心標準溫濕度（0-40℃，20%-80% 濕度）內穩定工作，適應長期高負載環境。
- 組網靈活：支持 LACP 鏈路聚合，可綁定多端口提升帶寬與冗余；兼容 MSTP 生成樹協議，構建無環拓?fù)?，適配數據中心葉脊核心層、大型園區網骨干層等多場景。
Extreme Networks BDXA-40G24X交換機模塊 英文資料：
Core Adaptation: Extreme Networks BDXA-40G24X is a high-density 40G optical port expansion module that is compatible with the Extreme Switching series of high-end chassis switches. It is designed specifically for high port density scenarios and meets the bandwidth expansion needs of large-scale equipment interconnection in data centers.
Interface specifications: Equipped with 24 40GBASE-X QSFP+optical ports, with a single port speed of 40Gbps, it can be paired with single-mode (transmission distance ≤ 40 kilometers) and multi-mode (transmission distance ≤ 100 meters) QSFP+optical modules to flexibly adapt to device interconnection scenarios at different distances.
Performance support: Adopting a non blocking line speed architecture, the overall throughput is bottleneck free, and the single port forwarding rate is stable at 40Gbps. It can efficiently carry high-frequency and high bandwidth services such as server cluster interconnection and large traffic data backup, ensuring smooth transmission.
Management compatibility: Seamless integration with the Extreme Management Center (XMC) platform, supporting batch configuration of VLAN and QoS priorities, compatible with the SNPv3 protocol, capable of real-time monitoring of port traffic and module status, achieving centralized operation and maintenance control.
Security protection: equipped with hardware level ACL access control, which can restrict data access based on IP and MAC addresses; Support port security binding, prevent illegal device access, and resist common network attacks such as ARP spoofing and DHCP flooding.
Reliable deployment: supports hot swappable design, can be replaced online in case of failure without interrupting business; Adapt to the redundant power architecture of switches, coupled with a fast detection mechanism for link failures, to enhance the continuity and reliability of network operation.
Convenience of operation and maintenance: Equipped with ports and global status indicator lights, it intuitively displays connection, speed, and operating status; Support remote fault diagnosis, allowing users to view error frames, optical power, and other parameters through the management platform for quick troubleshooting.
Environmental adaptability: Adopting low-power QSFP+optical port design, the energy consumption is better than that of high-density modules of the same type, and it can work stably within the standard temperature and humidity range (0-40 ℃, 20% -80% humidity) of the data center, adapting to long-term high load environments.
Flexible networking: Supports LACP link aggregation, can bind multiple ports to improve bandwidth and redundancy; Compatible with MSTP spanning tree protocol, building an acyclic topology, adapting to multiple scenarios such as data center spine core layer and large-scale park network backbone layer.
Extreme Networks BDXA-40G24X交換機模塊 產品展示
產品視頻
