Extreme Networks 220-48P-10GE4托管交換機
1.產 品 資 料 介 紹：
- 型號屬性：Extreme 220-48P-10GE4 是 Extreme Networks 旗下中端 1U 機架式全千兆 PoE + 托管交換機，主打中小企業匯聚層與高端接入層組網，“48P” 代表 48 個 PoE + 電口，“10GE4” 代表 4 個 10G SFP + 萬兆上行口，相比 210 系列升級上行速率，兼顧高密度供電與高速回傳。
- 端口配置：48 個 10/100/1000Base-TX PoE + 電口（支持 IEEE 802.3af/at，單口最大 30W）+4 個 10G Base-X SFP + 光口（萬兆上行），電口支持速率自適應，光口兼容萬兆多模 / 單模 SFP + 模塊，適配光纖高速上行場景。
- 關鍵性能：交換容量 192Gbps，包轉發率 143Mpps，總 PoE 功率 370W（典型值），支持 Jumbo 幀（最大 9216 字節），MAC 地址表容量 32K，滿足 48 路 PoE 終端滿配供電，同時通過萬兆上行解決千兆回傳瓶頸。
- 萬兆上行突破：4 個 SFP + 萬兆上行口，單口速率達 10Gbps，相比傳統千兆上行帶寬提升 10 倍，適配 4K/8K 監控視頻、大數據備份、云應用訪問等大流量場景，避免上行鏈路擁堵。
- PoE + 供電延續：單端口 30W 輸出，可同時為 Wi-Fi 6/6E 無線 AP、高清 IP 攝像頭、智能會議終端供電，減少電源布線成本，支持 “端口定時供電” 功能，可按需啟停終端設備，降低能耗。
- 進階管理能力：支持 Web UI、CLI 及 ExtremeCloud IQ 標準版平臺，可實現多設備批量配置、流量可視化分析（如實時監控各端口帶寬占用），兼容 “零接觸部署”，新設備通電后自動同步配置，簡化運維。
- 安全與可靠升級：除 802.1X、ACL 等基礎防護外，新增 “動態 ARP 檢測（DAI）”，防止 ARP 欺騙攻擊；支持 MSTP 多生成樹協議，可按 VLAN 規劃轉發路徑，提升網絡鏈路利用率；支持雙電源冗余（部分版本），保障設備不間斷運行。
Extreme Networks 220-48P-10GE4托管交換機 英文資料：
1、 Quick overview of core parameters
Model attribute: Extreme 220-48P-10GE4 is a mid-range 1U rack mounted full gigabit PoE+managed switch under Extreme Networks, focusing on small and medium-sized enterprise aggregation layer and high-end access layer networking. "48P" represents 48 PoE+ports, and "10GE4" represents 4 10G SFP+10 Gigabit uplink ports. Compared with the 210 series, it upgrades the uplink speed and balances high-density power supply and high-speed backhaul.
Port configuration: 48 10/100/1000Base TX PoE+electrical ports (supporting IEEE 802.3af/at, maximum 30W per port)+4 10G Base-X SFP+optical ports (10 Gigabit uplink), electrical ports support rate adaptation, optical ports are compatible with 10 Gigabit multimode/single-mode SFP+modules, suitable for high-speed fiber uplink scenarios.
Key performance: Switching capacity of 192Gbps, packet forwarding rate of 143Mpps, total PoE power of 370W (typical value), support for jumbo frames (maximum 9216 bytes), MAC address table capacity of 32K, meeting the full power supply of 48 PoE terminals, and solving the bottleneck of gigabit backhaul through 10G uplink.
2、 Core functions and values
10 Gigabit uplink breakthrough: 4 SFP+10 Gigabit uplink ports, single port speed up to 10Gbps, 10 times higher than traditional gigabit uplink bandwidth, suitable for high traffic scenarios such as 4K/8K surveillance video, big data backup, cloud application access, etc., avoiding uplink congestion.
PoE+Power Supply Continuation: Single port 30W output, can simultaneously supply power to Wi Fi 6/6E wireless APs, high-definition IP cameras, and smart conference terminals, reducing power wiring costs. Supports "port timed power supply" function, can start and stop terminal devices as needed, reducing energy consumption.
Advanced management capabilities: Supports Web UI, CLI, and ExtremeCloud IQ standard version platform, enabling batch configuration of multiple devices, visual analysis of traffic (such as real-time monitoring of bandwidth usage of each port), compatible with "zero touch deployment", automatically synchronizes configuration after new devices are powered on, simplifying operation and maintenance.
Security and reliability upgrade: In addition to basic protections such as 802.1X and ACL, "Dynamic ARP Detection (DAI)" has been added to prevent ARP spoofing attacks; Support MSTP multi spanning tree protocol, which can plan forwarding paths according to VLANs and improve network link utilization; Support dual power redundancy (some versions) to ensure uninterrupted operation of equipment.
Extreme Networks 220-48P-10GE4托管交換機 產品展示
產品視頻
