AMAT Applied Materials 03-81813-00印刷電路板
1.產 品 資 料 介 紹：
類別 | 規格 |
基板材質 | 玻璃纖維增強環氧樹脂（FR-4），Tg≥150℃ |
布線層數 | 6 層，線寬 / 線距≥3mil/3mil，阻抗控制 ±10% |
接口特性 | 集成 2 路 RS-485、4 路數字 I/O、2 路電源接口 |
環境適配 | -10-60℃、濕度＜85%、抗 EMI 干擾（EN 61000-6-2） |
兼容性 | 兼容 AMAT 0100-00985 智能接口板、0225-01622 控制器 |
- 信號中轉處理：接收傳感器（如溫度、壓力傳感器）信號，經濾波、放大后傳輸至控制器，保障數據精準性。
- 執行器驅動：輸出控制信號，驅動氣缸（如 3020-00121）、電磁閥等執行元件，實現設備動作控制。
- 子系統聯動：連接射頻互鎖模塊（如 0100-35565）與主控單元，傳遞安全聯鎖信號，保障設備運行安全。
- 安裝：固定于設備電控板卡插槽，金手指清潔無氧化，接線端子緊固扭矩 1-1.5N?m。
- 維護：每 6 個月檢查焊點無虛焊、基板無變形，每年校準板載信號放大電路精度，故障優先排查接口接觸狀態。
- 采購：優先選原廠供應商（如長欣自動化），到貨驗證基板材質報告與尺寸公差檢測報告。
AMAT Applied Materials 03-81813-00印刷電路板 英文資料：
1、 Core positioning
AMAT 03-81813-00 is the "signal processing and control carrier" for semiconductor equipment, responsible for the signal reception, operation processing, and instruction issuance functions of equipment subsystems (such as sensors and actuators). It adopts high-density wiring and anti-interference design, and is suitable for Class 100 clean environments and high-frequency signal transmission scenarios.
2、 Key parameters
Category
Specifications
Substrate material
Glass fiber reinforced epoxy resin (FR-4), Tg ≥ 150 ℃
Number of wiring layers
6 layers, line width/spacing ≥ 3mil/3mil, impedance control ± 10%
Interface characteristics
Integrate 2 RS-485 channels, 4 digital I/O channels, and 2 power interfaces
Environmental adaptation
-10-60 ℃, humidity<85%, anti EMI interference (EN 61000-6-2)
Compatibility
Compatible with AMAT 0100-00985 intelligent interface board and 0225-01622 controller
3、 Core applications
Signal relay processing: Receive sensor signals (such as temperature and pressure sensors), filter and amplify them, and transmit them to the controller to ensure data accuracy.
Actuator driver: outputs control signals to drive actuators such as cylinders (such as 3020-00121) and solenoid valves, achieving device action control.
Subsystem linkage: Connect the RF interlock module (such as 0100-35565) with the main control unit, transmit safety interlock signals, and ensure the safe operation of the equipment.
4、 Key points of operation and maintenance
Installation: Fixed in the slot of the electronic control board of the equipment, with clean and oxidation free gold fingers, and a tightening torque of 1-1.5N · m for the wiring terminals
Maintenance: Check for solder joints and substrate deformation every 6 months, calibrate the accuracy of onboard signal amplification circuits annually, and prioritize troubleshooting interface contact status for faults.
Procurement: Prioritize selecting original suppliers (such as Changxin Automation), and verify the substrate material report and dimensional tolerance inspection report upon arrival.
5、 Technical value
High density wiring improves signal transmission efficiency, anti-interference design reduces environmental interference, is compatible with multiple device components, and reduces the complexity of semiconductor equipment electrical control systems.
AMAT Applied Materials 03-81813-00印刷電路板 產品展示
產品視頻
