AMAT Applied Materials 0100-02839機架組件
1.產 品 資 料 介 紹：
類別 | 規格 |
材質特性 | 冷軋鋼板（表面靜電噴塑），厚度 1.5-2mm |
結構尺寸 | 標準 19 英寸機架，高度 4U（177.8mm），深度 450mm |
承重能力 | 均勻承重≤50kg，單點承重≤15kg |
環境適配 | -10-60℃、耐化學腐蝕（HF/Cl? 防護）、防塵等級 IP54 |
兼容性 | 兼容 AMAT 0100-00985 智能接口板、0010-30708 分析電源組件 |
- 組件集成安裝：固定電控板卡、電源模塊，實現設備核心部件的規整布局，便于布線與檢修。
- 結構支撐防護：為射頻互鎖模塊（如 0100-35565）、檢測器（如 0190-09445）提供穩定支撐，避免振動導致部件移位。
- 環境隔離保護：通過防塵、防腐設計，隔絕潔凈車間粉塵與工藝腐蝕性氣體，延長內部組件壽命。
- 安裝：水平固定于設備機柜，確保機架與地面垂直度偏差≤0.5°，組件安裝時均勻分布重量。
- 維護：每 3 個月清潔表面粉塵（用無塵布蘸異丙醇擦拭），每 12 個月檢查連接件緊固狀態，防止螺絲松動。
- 采購：優先選原廠供應商（如賽米卡爾電子），到貨驗證材質厚度、承重測試報告與尺寸公差。
AMAT Applied Materials 0100-02839機架組件 英文資料：
1、 Core positioning
AMAT 0100-02839 is the "structural support and component integration center" for semiconductor equipment, used to fix core components such as electronic control boards (such as 03-81813-00 PCB), power modules, interface components, etc. It adopts modular design and anti-corrosion treatment, and is suitable for Class 100 clean environment and equipment lightweight and high-density installation requirements.
2、 Key parameters
Category
Specifications
Material characteristics
Cold rolled steel plate (surface electrostatic spraying), thickness 1.5-2mm
Structural dimensions
Standard 19 inch rack, height 4U (177.8mm), depth 450mm
Load bearing capacity
Uniform load-bearing capacity ≤ 50kg, single point load-bearing capacity ≤ 15kg
Environmental adaptation
-10-60 ℃, resistant to chemical corrosion (HF/Cl ? protection), dustproof level IP54
Compatibility
Compatible with AMAT 0100-00985 intelligent interface board and 0010-30708 analysis power component
3、 Core applications
Component integration installation: Fix the electronic control board and power module to achieve a regular layout of the core components of the equipment, facilitating wiring and maintenance.
Structural support protection: Provide stable support for RF interlock modules (such as 0100-35565) and detectors (such as 0190-09445) to avoid component displacement caused by vibration.
Environmental isolation protection: Through dust-proof and anti-corrosion design, clean workshop dust and process corrosive gases are isolated, extending the service life of internal components.
4、 Key points of operation and maintenance
Installation: Fix horizontally on the equipment cabinet, ensuring that the vertical deviation between the rack and the ground is ≤ 0.5 °, and distribute the weight evenly during component installation.
Maintenance: Clean the surface dust every 3 months (wipe with a dust-free cloth dipped in isopropanol), and check the fastening status of the connectors every 12 months to prevent screws from loosening.
Procurement: Prioritize selecting original suppliers (such as Semicar Electronics), verify material thickness, load-bearing test reports, and dimensional tolerances upon arrival.
5、 Technical value
Modular design improves component installation efficiency, anti-corrosion and dustproof characteristics ensure equipment stability, standardized dimensions are compatible with multiple types of components, and reduces the difficulty of equipment structural modification.
