AMAT Applied Materials 03-81830-00印刷電路板
1.產 品 資 料 介 紹：
類別 | 規格 |
基板材質 | 玻璃纖維增強環氧樹脂（FR-4），Tg≥160℃（耐高溫性更優） |
布線層數 | 8 層（高密度布線），線寬 / 線距≥2.5mil/2.5mil，阻抗控制 ±8%（精度更高） |
接口特性 | 集成 3 路 RS-485、6 路數字 I/O、3 路模擬 I/O、1 路 Ethernet（支持?jǐn)?shù)據交互） |
環境適配 | -15-65℃（溫域更廣）、濕度＜80%、抗 EMI 干擾（EN 61000-6-3 標準） |
兼容性 | 兼容 AMAT 0100-02839 機架組件、0225-01622 控制器、0100-00985 智能接口板 |
- 高精度信號處理：接收等離子弧電流板（如 0100-90642）、檢測器（如 0190-09445）的微弱信號，經濾波、放大后傳輸至控制器，保障工藝數據精準度。
- 執行器精準驅動：輸出控制信號，驅動氣缸（3020-00121）、射頻匹配組件（0041-78374）等執行元件，實現微米級動作控制或射頻功率調節。
- 多子系統聯動：連接射頻互鎖模塊（0100-35565）與安全控制系統，傳遞聯鎖信號，確保危險場景下快速切斷電源，保障設備與人員安全。
- 安裝：適配 0100-02839 機架組件的標準卡槽，金手指需用無塵布蘸異丙醇清潔（避免氧化），接線端子緊固扭矩 1.2-1.8N?m（防止接觸不良）。
- 維護：每 6 個月檢查焊點無虛焊、基板無變形開裂；每年用示波器校準信號傳輸精度；故障優先排查接口接觸狀態或板載濾波電容（易老化部件）。
- 采購：優先選原廠供應商（如長欣自動化、賽米卡爾電子），到貨需驗證基板材質報告、阻抗測試報告及尺寸公差（確保適配機架安裝）。
AMAT Applied Materials 03-81830-00印刷電路板 英文資料：
1、 Core positioning
AMAT 03-81830-00 is the "signal processing and driving carrier" of semiconductor equipment electronic control systems, responsible for sensor signal acquisition, actuator command output, and subsystem collaborative control functions. It adopts high-precision wiring and anti-interference design, adapts to Class 100 clean environment and high-frequency signal transmission requirements, and ensures stable equipment process parameters.
2、 Key parameters
Category
Specifications
Substrate material
Glass fiber reinforced epoxy resin (FR-4), Tg ≥ 160 ℃ (better high temperature resistance)
Number of wiring layers
8 layers (high-density wiring), line width/spacing ≥ 2.5mil/2.5mil, impedance control ± 8% (higher accuracy)
Interface characteristics
Integrated with 3 RS-485 channels, 6 digital I/O channels, 3 analog I/O channels, and 1 Ethernet channel (supporting data exchange)
Environmental adaptation
-15-65 ℃ (wider temperature range), humidity<80%, anti EMI interference (EN 61000-6-3 standard)
Compatibility
Compatible with AMAT 0100-02839 rack components, 0225-01622 controller, 0100-00985 intelligent interface board
3、 Core applications
High precision signal processing: Receive weak signals from plasma arc current plates (such as 0100-90642) and detectors (such as 0190-09445), filter and amplify them, and transmit them to the controller to ensure the accuracy of process data.
Precise actuator drive: Output control signals to drive actuators such as cylinders (3020-00121) and RF matching components (0041-78374), achieving micrometer level action control or RF power regulation.
Multi subsystem linkage: Connect the RF interlock module (0100-35565) with the safety control system, transmit interlock signals, ensure rapid power cut-off in hazardous scenarios, and safeguard equipment and personnel safety.
4、 Key points of operation and maintenance
Installation: Suitable for the standard card slot of the 0100-02839 rack component. The gold fingers should be cleaned with a dust-free cloth dipped in isopropanol (to avoid oxidation), and the tightening torque of the wiring terminals should be 1.2-1.8N · m (to prevent poor contact).
Maintenance: Check the solder joints for virtual soldering and the substrate for deformation and cracking every 6 months; Calibrate the signal transmission accuracy with an oscilloscope every year; Prioritize troubleshooting interface contact status or onboard filtering capacitors (components prone to aging).
Procurement: Prioritize the selection of original suppliers (such as Changxin Automation, Semicar Electronics), and upon arrival, verify the substrate material report, impedance test report, and dimensional tolerances (to ensure compatibility with rack installation).
AMAT Applied Materials 03-81830-00印刷電路板 產品展示
產品視頻
