AMAT Applied Materials 0100-00985智能接口組件板
1.產 品 資 料 介 紹：
類別 | 規格 |
接口類型 | 4 路 RS-485、2 路 Ethernet、8 路數字 I/O、4 路模擬 I/O |
協議兼容 | 支持 Modbus-RTU、Profinet、TCP/IP 協議 |
數據速率 | 以太網≤100Mbps，RS-485≤1Mbps |
隔離特性 | 電源 / 信號雙重隔離，隔離電壓≥2500V DC |
環境適配 | -10-60℃、IP40、抗 EMI 干擾（EN 61000-6-2） |
兼容性 | 兼容 AMAT 0225-01622 控制器、0100-20001 電子接口模塊 |
- 跨模塊信號轉換：將傳感器模擬信號（如溫度 4-20mA）轉為數字信號，傳輸至控制器優化工藝參數。
- 總線協議適配：實現 PLC 與射頻匹配組件（如 0041-78374）的 Profinet 協議通信，保障指令實時下發。
- 設備狀態匯總：采集氣缸、互鎖模塊等組件狀態數據，統一上傳至 HMI，便于運維人員監控。
- 安裝：固定于電控柜 DIN 導軌，屏蔽線單端接地（≤0.5Ω），遠離射頻電源模塊。
- 維護：每 3 個月檢查網口 / 端子接觸狀態，每 6 個月備份協議配置參數，故障優先排查協議地址沖突。
- 采購：優先選原廠供應商（如賽米卡爾電子），到貨驗證協議兼容性測試報告與序列號溯源。
AMAT Applied Materials 0100-00985智能接口組件板 英文資料：
1、 Core positioning
AMAT 0100-00985 is a "multi protocol signal interaction hub" for semiconductor equipment, responsible for integrating analog/digital signals, converting industrial bus protocols (such as Modbus, Profinet), achieving efficient data exchange between controllers, sensors, and actuators, and adapting to Class 100 clean environments and high-frequency electromagnetic interference scenarios.
2、 Key parameters
Category
Specifications
Interface type
4-channel RS-485, 2-channel Ethernet, 8-channel digital I/O, 4-channel analog I/O
Protocol compatibility
Supports Modbus RTU, Profinet, TCP/IP protocols
Data rate
Ethernet ≤ 100Mbps, RS-485 ≤ 1Mbps
Isolation characteristics
Dual isolation of power/signal, isolation voltage ≥ 2500V DC
Environmental adaptation
-10-60 ℃ IP40、 Anti EMI interference (EN 61000-6-2)
Compatibility
Compatible with AMAT 0225-01622 controller and 0100-20001 electronic interface module
3、 Core applications
Cross module signal conversion: Convert sensor analog signals (such as temperature 4-20mA) into digital signals and transmit them to the controller to optimize process parameters.
Bus protocol adaptation: Implement Profinet protocol communication between PLC and RF matching components (such as 0041-78374) to ensure real-time instruction issuance.
Equipment status summary: Collect status data of components such as cylinders and interlock modules, and upload them to HMI for easy monitoring by operation and maintenance personnel.
4、 Key points of operation and maintenance
Installation: Fixed to the DIN rail of the electrical control cabinet, shielded wire with single end grounding (≤ 0.5 Ω), away from the RF power module.
Maintenance: Check the network port/terminal contact status every 3 months, backup protocol configuration parameters every 6 months, and prioritize troubleshooting protocol address conflicts.
Procurement: Prioritize the selection of original suppliers (such as Semicar Electronics), and provide compatibility testing reports and serial number traceability for the arrival verification protocol.
5、 Technical value
Multi protocol integration reduces the number of interface modules, dual isolation improves signal stability, is compatible with multi device systems, and reduces semiconductor equipment wiring and debugging costs.
