Control Techniques UNI3403變速驅動器

1.產 品 資 料 介 紹：

產品概述

Control Techniques UNI3403 是一款 工業級交流（AC）變速驅動器，用于控制小型至中型交流電機的轉速、扭矩和方向。它屬于 UniDrive 系列，專為中低功率工業設備設計，提供平穩調速、節能運行及電機保護功能。該驅動器常用于輕工業自動化、泵風機系統及實驗臺等場景。

技術參數

• 型號：UNI3403

• 類型：交流電機變速驅動器（AC Drive / VFD）

• 電機類型：三相異步電機

• 額定功率：約 3 kW（具體依型號配置）

• 輸入電源：三相 380–480 V AC 或單相 200–240 V AC（視型號而定）

• 輸出電壓/頻率：可調，支持變頻調速

• 控制方式：

  • V/F（電壓/頻率）控制

  • 矢量控制（開環或閉環，可選）

• 保護功能：過載、過壓、欠壓、短路、過熱保護

• 通信接口：部分型號支持 Modbus、數字/模擬接口

• 安裝方式：模塊化設計，適合壁掛或機柜安裝

應用場景

1. 輕中型工業設備：輸送帶、攪拌機、包裝機等連續生產設備

2. 泵與風機系統：實現流量、壓力及轉速的精確控制，降低能耗

3. 實驗與研發：電機測試臺、研發實驗設備的變速控制

4. HVAC 系統：風機、水泵及空調系統的節能調速

5. 小型自動化生產線：輕工、食品、紡織等行業的中低功率電機控制

Control Techniques UNI3403變速驅動器 英文資料：

Product Overview

Control Techniques UNI3403 is an industrial grade AC variable speed drive used to control the speed, torque, and direction of small to medium-sized AC motors. It belongs to the UniDrive series, designed specifically for low to medium power industrial equipment, providing smooth speed regulation, energy-saving operation, and motor protection functions. This driver is commonly used in scenarios such as light industry automation, pump fan systems, and experimental benches.

Technical Specifications

Model: UNI3403

Type: AC Drive/VFD

Motor type: Three phase asynchronous motor

Rated power: approximately 3 kW (specific configuration according to model)

Input power supply: three-phase 380-480 V AC or single-phase 200-240 V AC (depending on the model)

Output voltage/frequency: adjustable, supports variable frequency speed regulation

Control method:

V/F (voltage/frequency) control

Vector control (open-loop or closed-loop, optional)

Protection functions: overload, overvoltage, undervoltage, short circuit, overheating protection

Communication interface: Some models support Modbus, digital/analog interfaces

Installation method: Modular design, suitable for wall mounted or cabinet installation

Application scenarios

Light and medium-sized industrial equipment: continuous production equipment such as conveyor belts, mixers, packaging machines, etc

Pump and fan system: achieve precise control of flow, pressure, and speed to reduce energy consumption

Experiment and R&D: Variable speed control of motor testing bench and R&D experimental equipment

HVAC system: energy-saving speed regulation of fans, water pumps, and air conditioning systems

Small scale automated production line: low to medium power motor control for industries such as light industry, food, and textile

Control Techniques UNI3403變速驅動器 產品展示

 產品視頻
