Woodward PROTECH-SX 8237-1242渦輪機控制器
1.產 品 資 料 介 紹：
中文資料：
Woodward 的 PROTECH-SX（零件號 8237-1242）是一款集成超速保護的安全系統，專為渦輪機應用設計，確保在超速情況下對渦輪機進行快速、安全的停機操作。
主要功能：
超速保護：在檢測到渦輪機超速時，系統會迅速觸發停機，防止設備損壞或安全事故。
三重冗余架構：采用三重冗余設計，提高系統可靠性，確保在單個組件故障時仍能正常運行。
可配置參數：用戶可根據具體應用需求設置超速觸發點和其他關鍵參數。
技術規格：
電源要求：支持高壓/低壓（HV/LV）電源配置。
輸入信號：兼容多種速度傳感器輸入，包括磁性拾波器和接近探頭。
輸出信號：提供多路繼電器輸出，用于觸發渦輪機停機或報警。
環境條件：設計用于工業環境，能夠在寬溫度范圍和高濕度條件下穩定運行。
應用領域：
燃氣渦輪機：用于發電廠和工業設施中的燃氣渦輪機超速保護。
蒸汽渦輪機：在電廠和其他應用中保護蒸汽渦輪機免受超速損壞。
水力渦輪機：確保水力發電設備的安全運行。
英文資料：
Woodward's PROTECH-SX (part number 8237-1242) is an integrated overspeed protection safety system designed specifically for turbine applications, ensuring quick and safe shutdown of the turbine in the event of overspeed.
Main functions:
Overspeed protection: When the turbine overspeed is detected, the system will quickly trigger a shutdown to prevent equipment damage or safety accidents.
Triple redundancy architecture: Adopting a triple redundancy design to improve system reliability and ensure normal operation in the event of a single component failure.
Configurable parameters: Users can set overspeed trigger points and other key parameters according to specific application requirements.
Technical specifications:
Power requirements: Supports high/low voltage (HV/LV) power configuration.
Input signal: Compatible with multiple speed sensor inputs, including magnetic pickups and proximity probes.
Output signal: Provides multiple relay outputs for triggering turbine shutdown or alarm.
Environmental conditions: Designed for industrial environments, capable of stable operation over a wide temperature range and high humidity conditions.
Application areas:
Gas turbine: Used for overspeed protection of gas turbines in power plants and industrial facilities.
Steam turbine: protects steam turbines from overspeed damage in power plants and other applications.
Hydraulic turbine: Ensure the safe operation of hydroelectric power generation equipment.
2.產 品 展 示
