Control Techniques ES3403變頻器

1.產 品 資 料 介 紹：

產品概述

Control Techniques ES3403 是一款 工業級交流（AC）變頻器，用于調節交流電機的轉速和扭矩，實現高性能的電機控制。該變頻器設計緊湊、可靠性高，適用于工業自動化生產線、泵、風機、壓縮機等設備的精確驅動控制。

技術參數

• 型號：ES3403

• 類型：交流變頻器（AC Drive / VFD）

• 電機類型：三相異步電機

• 額定功率：約 3 kW（具體依型號配置）

• 輸入電源：?jiǎn)蜗嗷蛉?200–240 V AC

• 輸出：可調電壓及頻率，實現變頻調速

• 控制方式：

  • V/F（電壓/頻率）控制

  • 矢量控制（部分型號支持閉環）

• 保護功能：過載、過壓、欠壓、短路、過溫保護

• 通信接口：部分型號支持 Modbus、數字/模擬接口

• 安裝方式：壁掛式或機柜安裝，模塊化設計

應用場景

1. 工業自動化設備：傳送帶、包裝機、攪拌機、機械手驅動

2. 泵與風機系統：實現流量、壓力和風量的精確控制，節能降耗

3. 輕中型機床與加工設備：控制電機轉速和扭矩，保證工藝精度

4. HVAC 系統：風機、水泵及空調設備的節能控制

5. 實驗與研發：電機測試臺及研發驗證場景

Control Techniques ES3403變頻器 英文資料：

Product Overview

Control Techniques ES3403 is an industrial grade AC frequency converter used to regulate the speed and torque of AC motors, achieving high-performance motor control. This frequency converter is designed to be compact and highly reliable, suitable for precise drive control of industrial automation production lines, pumps, fans, compressors and other equipment.

Technical Specifications

Model: ES3403

Type: AC Drive/VFD

Motor type: Three phase asynchronous motor

Rated power: approximately 3 kW (specific configuration according to model)

Input power supply: single-phase or three-phase 200-240 V AC

Output: Adjustable voltage and frequency, achieving variable frequency speed regulation

Control method:

V/F (voltage/frequency) control

Vector control (some models support closed-loop)

Protection functions: overload, overvoltage, undervoltage, short circuit, over temperature protection

Communication interface: Some models support Modbus, digital/analog interfaces

Installation method: wall mounted or cabinet installation, modular design

Application scenarios

Industrial automation equipment: conveyor belts, packaging machines, mixers, robotic arm drives

Pump and fan system: achieve precise control of flow rate, pressure, and air volume, saving energy and reducing consumption

Light and medium-sized machine tools and processing equipment: control motor speed and torque to ensure process accuracy

HVAC system: energy-saving control of fans, water pumps, and air conditioning equipment

Experiment and R&D: Motor Testing Platform and R&D Verification Scenarios

Control Techniques ES3403變頻器 產品展示

 產品視頻
