NI PXIE-5160示波器模塊
1.產 品 資 料 介 紹：
中文資料：
NI PXIe-5160 是由國家儀器（National Instruments）推出的一款高性能 PXI Express 示波器模塊，廣泛應用于需要高速信號采集和分析的領域。
主要技術規格：
通道數：提供兩通道和四通道兩種型號，所有通道均可同時采樣。
模擬帶寬：高達 500 MHz。
采樣率：最高可達 2.5 GS/s。
垂直分辨率：10 位。
輸入類型：采用 BNC 連接器的參考單端輸入。
耦合方式：支持交流（AC）或直流（DC）耦合。
輸入阻抗：軟件可選擇 50 Ω 或 1 MΩ，典型值分別為 50 Ω ± 1.50% 和 1 MΩ ± 0.75%。
輸入電容：典型值為 15 pF ± 0.8 pF。
板載內存：可選 64 MB 或 2 GB。
應用領域：
研發測試：在新產品開發階段，用于測試和驗證電子設備的性能是否符合設計規格。
制造與質量控制：在生產線上監測產品性能，確保產品在制造過程中滿足質量標準。
通信行業：分析和測試通信設備中的信號完整性，包括無線信號和高速數據傳輸。
汽車電子：測試和驗證汽車中的電子控制單元、傳感器和通訊系統。
PXIe-5160 示波器模塊的高帶寬和高采樣率使其非常適合需要精確信號測量和分析的應用場景。
英文資料：
NI PXIe-5160 is a high-performance PXI Express oscilloscope module launched by National Instruments, widely used in fields that require high-speed signal acquisition and analysis.
Main technical specifications:
Number of channels: Two channel and four channel models are available, and all channels can be sampled simultaneously.
Analog bandwidth: up to 500 MHz.
Sampling rate: up to 2.5 GS/s.
Vertical resolution: 10 bits.
Input type: Reference single ended input using BNC connector.
Coupling method: Supports alternating current (AC) or direct current (DC) coupling.
Input impedance: The software can ｓｅｌｅｃｔ 50 Ω or 1 M Ω, with typical values of 50 Ω± 1.50% and 1 M Ω± 0.75%, respectively.
Input capacitance: The typical value is 15 pF ± 0.8 pF.
Onboard memory: optional 64 MB or 2 GB.
Application areas:
R&D testing: During the new product development phase, it is used to test and verify whether the performance of electronic devices meets design specifications.
Manufacturing and Quality Control: Monitor product performance on the production line to ensure that the product meets quality standards during the manufacturing process.
Communication industry: Analyze and test signal integrity in communication equipment, including wireless signals and high-speed data transmission.
Automotive Electronics: Testing and validating electronic control units, sensors, and communication systems in automobiles.
The high bandwidth and sampling rate of the PXIe-5160 oscilloscope module make it highly suitable for applications that require precise signal measurement and analysis.
